4
AUTO BOOSTER
Original Instructions
1 Safety Precautions and Warnings
Symbols used to mark in-
structions
Before starting up
your high-pressure
washer for the fi rst
time, this instruc-
tion manual must
be read through carefully. Save
the instructions for later use.
Safety instruc-
tions marked with
this symbol must
be observed to
prevent danger to persons.
This symbol is
used to mark
safety instruc-
tions that must
be observed to
prevent damage
to the machine and its perfor-
mance.
This symbol
indicates tips and
instructions to
simplify work and to ensure a
safe operation.
This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabili-
ties, or lack of experience and
knowledge.
High pressure cleaners shall
not be used by children or un-
trained personnel.
Children should be supervised
to ensure that they do not play
with the appliance.
Warning
Inhalation of aerosols can be
hazardous to health.
Where applicable use a device
in order to avoid or reduce aer-
osols production, e.g., a shield
covering the nozzle.
For protection against aerosols
use a respiratory mark of class
FFP 2 or higher.
General
When using the high-pressure
hot water washer all existing
national regulations must be
observed. Beyond the instruc-
tion manual and the current
national legal regulations for
prevention of accidents, also
the approved rules for safe
working must be observed.
Any method of use endangering
the safety of persons or equip-
ment is forbidden.
Before use
Before starting up your high-
pressure hot water washer
check that it is in a regular
condition. Electric plugs and
couplings must be watertight.
Check the electric cables at
regular intervals for damage
and wear. Only use the high-
pressure hot water washer if the
electric cable is all right (dam-
aged electric cables can cause
electric shock!)
Important instructions
Connection to public drinking
water supply must be per-
formed in accordance with the
applicable regulations in your
country.
IMPORTANT: Only use water
without impurities!
Before each use of your high-
pressure hot water washer
check the most important visual
parts.
High-pressure jets can be dan-
gerous if misused. Never direct
the water jet towards people,
pets, electric wiring, or the ma-
chine itself.
Spray handle and lance are af-
fected by a thrust during opera-
tion - therefore always hold the
spray lance fi rmly with both
hands.
Never try to clean clothes or
footwear on yourself or other
persons.
Operator and anyone in imme-
diate vicinity of the site of clean-
ing should take action to protect
himself from being struck by
debris dislodged during opera-
tion.
Check that cleaning will not
result in dangerous substances
(e.g. asbestos, oil) being
washed off the object to be
