20
AUTO BOOSTER
Original Instructions
3. Close the door of the AUTO BOOSTER, and lock the two key-
locks.
4. Position the program selector switch (3) in position “STOP”.
5. The AUTO BOOSTER is now operative.
By inserting valid coins or coins through the coin inlet, the display
will show the payment, summing up as more coins are inserted.
!! NOTE: The machine will start when the preset “minimum
payment” has been reached. Insert of more coins will increase the
time.
4.2.2 Stopping the AUTO
BOOSTER
!! NOTE: In case of emergency turn the program selec-
tor switch (3) to STOP, or push the optional “Emergency
Switch” !!
When pay time runs out (display at 00:00) the AUTO BOOSTER
will automatically stop and relieve pressure from the hose/spray
handle, no matter where the program selector switch is positioned.
If working is terminated for more than 90 seconds during pay-time
(closed handle), the AUTO BOOSTER will enter standby mode,
and the HP pump will stop. The boost button will start fl ashing.
Working can be resumed by pressing the boost button, as long as
pay time has not expired.
!! NOTE: Do not disconnect the AUTO BOOSTER from
main power supply, neither by turning AUTO BOOSTERs
main switch to position “OFF”, nor by interrupting external
installation switches as this will leave the AUTO
BOOSTERs automatic frost protection device inoperative.
