Laserliner Quadrum DigiPlus 410 S 053.300A [13/244] Quadrum digiplus quadrum digiplus green

Quadrum DigiPlus / Quadrum DigiPlus Green

IP 66

Please read the operating instructions as well as the enclosed brochures „Guarantee and

additional notices“ and „Laser class 3R safety instructions“. Follow the instructions they

contain. Safely keep these documents for future reference.

Two-axis grade laser with red or green laser technology.

– With additional red plumb laser

– Laser modes: spot, scan, rotary and hand receiver mode

– The laser modes can be set using the remote control.

– optional SensoLite 310: Laser receiver range up to 300 m radius

– optional SensoLite 410: Laser receiver range up to 400 m radius

– optional SensoMaster 400 (Quadrum DigiPlus red only): Laser receiver range in excess of 300 m

radius. With longer laser receiver unit and millimetre exact distance reading for laser level.

Caution: Prior to using the laser, you must read the safety instructions for laser class 3R thoroughly.

Warning signs must not be removed from the laser measuring device! Do not look directly into the

beam. Lasers must be kept out of reach of children. Never intentionally aim the device at people.

This is a quality laser measuring device and is 100% factory adjusted within the stated tolerance. For

reasons of product liability, we must also draw your attention to the following: Regularly check the

calibration before use, after transport and after extended periods of storage. We also wish to point

out that absolute calibration is only possible in a specialist workshop. Calibration by yourself is only

approximate and the accuracy of the calibration will depend on the care with which you proceed.

Laser radiation!

Avoid direct exposure

to the eyes.

Laser class 3R

< 5 mW Ċ 530 - 670 nm

EN60825-1:2007-10

General safety instructions

Special product features and functions

The device characterised by specific protection against dustand rain.

Transport LOCK: The device is protected by a special motor brake during transport.

The rotary laser aligns itself automatically. It is set to the required initial position (to within

an operating angle of ± 6°) and the automatic system then performs the necessary fine

adjustment, with three electronic measurement sensors detecting the X, Y and Z axes.
