Pioneer AVH-P7800DVD [13/280] Exterior 1 section parts list
![Pioneer AVH-P7800DVD [13/280] Exterior 1 section parts list](/views2/1616063/page13/bgd.png)
AVH-P7800DVD/UC
13
5678
56
7
8
C
D
F
A
B
E
EXTERIOR(1) SECTION PARTS LIST
Mark No. Description Part No.
1 Mother Unit CWN1496
2 Cord Assy CDE8097
3 Cord Assy CDE8095
4 Cord Assy CDE8094
5 Cord Assy CDE8093
6 Terminal(CN951) CKF1064
7 Terminal(CN952) CKF1064
8 Terminal(CN3301) CKF1064
9 Terminal(CN3302) CKF1064
10 Plug(CN232) CKS-463
11 Connector(CN3201) CKS2600
12 Connector(CN752) CKS5566
13 Connector(CN871) CKS4822
14 Connector(CN851) CKS4823
15 Connector(CN701) CKS5045
16 Connector(CN702) CKS5100
17 Connector(CN571) CKS5113
18 Connector(CN751) CKS5492
19 Connector(CN753) CKS5494
20 Connector(CN651) CKS5501
21 Connector(CN572) CKS5533
22 Connector(CN231) CKS4674
23 Holder CND3497
24 Screw BPZ20P060FTC
25 Button(V.ADJUST, ENT, WIDE) CAC9689
26 Flat Cable CDE8105
27 Touch Panel CSX1098
28 Monitor Keyboard Unit CWN1517
29 Connector(CN6001) CKS5033
30 Screw(M2 x 2) CBA1872
31 Holder CND3222
32 Sheet CNN1071
33 Sheet CNN1072
34 Insulator CNN1073
35 Monitor Unit CWN1505
36 Checker Chip(CN4001) CKF1031
37 Checker Chip(CN4002) CKF1031
38 Checker Chip(CN4003) CKF1031
39 Terminal(CN5603) CKF1068
40 Terminal(CN5604) CKF1068
41 Terminal(CN5605) CKF1068
42 Connector(CN5501) CKS4428
43 Connector(CN4801) CKS5033
44 Connector(CN5301) CKS5111
45 Connector(CN5602) CKS5532
46 Connector(CN5601) CKS5533
47 Connector(CN4701) CKS5561
48 LCD Module CWX3341
49 Grille Unit CXC6199
50 Screw BMZ26P030FTC
51 Screw(M2 x 2.5) CBA1624
52 Screw(M2 x 2) CBA1872
53 Flat Cable CDE8103
54 Flat Cable CDE8104
55 Screw(M2 x 1.4) CBA2042
56 Cover Unit CXC6200
57 Holder CND3271
58 Holder CND3210
59 Cover CND3639
60 Screw JFZ20P018FTC
61 Sheet CNN1524
62 Sheet CNN1525
63 Screw IMS20P50FTB
Mark No. Description Part No.
