AVH-P7800DVD/UC
166
1234
1234
C
D
F
A
B
E
D 8454 (B,51,17) Diode 1SS355
D 8456 (B,49,28) Diode 1SS355
D 8501 (B,171,102) Diode UDZS5R6(B)
D 8503 (B,159,52) Diode 1SR154-400
D 8504 (B,154,52) Diode 1SR154-400
D 8505 (B,148,54) Diode 1SR154-400
D 8601 (B,104,144) Diode UMZ6R8EN
D 8602 (B,100,144) Diode UMZ6R8EN
D 8603 (B,110,142) Diode UMZ6R8EN
D 8604 (B,107,144) Diode UMZ6R8EN
D 8605 (B,111,150) Diode HZU2R7(B1)
D 8606 (A,115,149) Diode HZU2R7(B1)
D 8607 (A,119,148) Diode HZU2R7(B1)
D 8608 (B,121,161) Diode HZU2R7(B1)
D 8609 (B,106,150) Diode HZU2R7(B1)
D 8610 (A,115,147) Diode HZU2R7(B1)
D 8611 (A,115,145) Diode HZU2R7(B1)
D 8612 (B,117,161) Diode HZU2R7(B1)
D 8651 (A,140,137) Diode S1G-6904G2P
D 8652 (A,140,134) Diode S1G-6904G2P
D 8701 (B,142,52) Diode UDZS5R6(B)
D 8702 (A,149,103) Diode 1SS355
D 8703 (B,133,98) Diode UDZS8R2(B)
D 8705 (B,152,159) Diode DAN202U
D 8706 (A,141,151) Diode 1SR154-400
D 8707 (A,154,150) Diode UDZS6R8(B)
D 8708 (A,141,148) Diode 1SR154-400
D 8709 (B,140,160) Diode HZU7L(C3)
D 8710 (B,148,135) Diode UDZS9R1(B)
D 8711 (A,157,119) Diode 1SR154-400
D 8712 (A,171,128) Diode UDZS5R6(B)
D 8751 (B,86,19) Diode MA153
D 8752 (B,91,20) Diode MA153
D 8801 (B,126,119) Diode DAP202K
D 8802 (B,125,89) Diode DAN202U
D 8803 (B,128,84) Diode DAN202U
D 8804 (B,117,91) Diode DAN202U
D 8806 (A,113,51) Diode DAP202K
D 8807 (B,119,84) Diode DAN202U
D 8901 (B,62,37) Diode UDZS20(B)
ZNR8501 (B,186,38) Surge Protector RCCA-201Q31UA-PI
L 8001 (A,34,95) Inductor CTF1379
L 8002 (A,32,69) Inductor CTF1379
L 8003 (A,27,69) Inductor CTF1379
L 8004 (A,29,97) Inductor LCKAW2R2J2520
L 8005 (A,15,80) Inductor CTF1379
L 8101 (A,96,95) Inductor CTF1473
L 8251 (A,131,17) Inductor CTF1473
L 8252 (A,139,25) Inductor CTF1473
L 8451 (A,49,9) Inductor CTF1379
L 8452 (B,46,24) Inductor CTF1473
L 8453 (A,42,25) Inductor CTF1473
L 8501 (B,189,45) Chip Coil LCTAW4R7J2520
L 8502 (B,183,93) Inductor LCYC2R2K2125
L 8503 (B,181,83) Inductor LCYC1R0K2125
L 8504 (B,186,56) Inductor LCYC1R0K2125
L 8601 (A,121,137) Inductor CTF1473
L 8602 (A,109,154) Inductor-Array CTF1542
L 8603 (A,109,150) Inductor-Array CTF1542
L 8604 (A,112,142) Inductor CTF1379
Circuit Symbol and No. Part No.
L 8701 (B,158,158) Inductor LCTC2R2K1608
L 8703 (A,158,150) Inductor CTF1295
L 8751 (A,92,18) Inductor LCYC100K2125
L 8771 (B,84,27) Chip Ferrite Bead CTF1399
L 8772 (B,87,27) Chip Ferrite Bead CTF1399
L 8901 (A,77,52) Inductor CTF1473
L 8902 (A,71,52) Inductor CTF1473
L 8903 (A,64,52) Inductor CTF1473
L 8904 (A,67,52) Inductor CTF1473
X 8001 (A,16,86) Radiator 18.874 MHz CSS1622
S 8251 (A,124,23) Switch(Video input) CSH1065
VR8751 (A,92,38) Semi-fixed CCP1479
VR8752 (A,96,38) Semi-fixed CCP1479
VR8901 (A,72,21) Semi-fixed CCP1477
VR8902 (A,64,21) Semi-fixed CCP1477
VR8903 (A,56,21) Semi-fixed CCP1477
>FU8251 (A,121,31) Fuse 3 A CEK1286
>FU8301 (A,115,27) Fuse 3 A CEK1286
>FU8451 (A,36,19) Fuse 3 A CEK1286
>FU8452 (A,34,19) Fuse 5 A CEK1289
>FU8601 (A,98,163) Fuse 3 A CEK1286
>FU8602 (A,119,146) Fuse 3 A CEK1286
>FU8751 (A,138,21) Fuse 3 A CEK1286
>FU8752 (A,170,18) Fuse 3 A CEK1286
>FU8901 (B,54,19) Fuse 5 A CEK1289
>FU8902 (A,77,20) Fuse 3 A CEK1286
>FU8903 (A,55,36) Fuse 3 A CEK1286
>FU8904 (A,62,35) Fuse 3 A CEK1286
>FU8905 (A,72,56) Fuse 3 A CEK1286
>FU8906 (A,66,57) Fuse 3 A CEK1286
>FU8907 (A,60,59) Fuse 3 A CEK1286
Y 8501 (A,191,49) FM/AM Tuner Unit CWE1806
RESISTORS
R 8004 (B,28,86) RS1/16S471J
R 8005 (B,46,87) RS1/16S473J
R 8006 (B,48,85) RS1/16S473J
R 8007 (B,48,83) RS1/16S104J
R 8008 (B,23,96) RS1/16S0R0J
R 8009 (B,39,80) RS1/16S473J
R 8011 (B,48,81) RS1/16S104J
R 8012 (B,32,85) RS1/16S471J
R 8014 (B,38,72) RS1/16S0R0J
R 8015 (B,37,80) RS1/16S473J
R 8016 (B,48,93) RS1/16S182J
R 8017 (A,41,76) RS1/16S0R0J
R 8018 (B,48,91) RS1/16S182J
R 8020 (A,24,92) RS1/16S0R0J
R 8021 (B,43,71) RS1/16S102J
R 8022 (B,44,94) RS1/16S681J
R 8023 (A,37,71) RS1/16S473J
R 8024 (B,44,98) RS1/16S471J
R 8025 (B,48,99) RS1/16S471J
R 8026 (B,38,96) RS1/16S681J
R 8028 (B,29,89) RS1/16S473J
R 8029 (B,23,94) RS1/16S473J
R 8030 (B,23,90) RS1/16S104J
R 8031 (B,12,62) RS1/16S681J
R 8034 (A,19,85) RS1/16S101J
Circuit Symbol and No. Part No.
