AVH-P7800DVD/UC
192
1234
1234
C
D
F
A
B
E
No. Signal name
Verification location 1 Verification location 2
Rated value
1 MA0 IC1481 pin25 IC1501 pin241 56 Ω 5 %
2 MA1 IC1481 pin26 IC1501 pin243
3 MA2 IC1481 pin27 IC1501 pin245
4 MA3 IC1481 pin60 IC1501 pin247
5 MA4 IC1481 pin61 IC1501 pin246
6 MA5 IC1481 pin62 IC1501 pin244
7 MA6 IC1481 pin63 IC1501 pin242
8 MA7 IC1481 pin64 IC1501 pin240
9 MA8 IC1481 pin65 IC1501 pin236
10 MA9 IC1481 pin66 IC1501 pin232
11 MA10 IC1481 pin24 IC1501 pin237
12 MA11 IC1481 pin21 IC1501 pin230
13 MDQ0 IC1481 pin2 IC1501 pin199
14 MDQ1 IC1481 pin4 IC1501 pin201
15 MDQ2 IC1481 pin5 IC1501 pin203
16 MDQ3 IC1481 pin7 IC1501 pin207
17 MDQ4 IC1481 pin8 IC1501 pin209
18 MDQ5 IC1481 pin10 IC1501 pin211
19 MDQ6 IC1481 pin11 IC1501 pin213
20 MDQ7 IC1481 pin13 IC1501 pin217
21 MDQ8 IC1481 pin74 IC1501 pin216
22 MDQ9 IC1481 pin76 IC1501 pin212
23 MDQ10 IC1481 pin77 IC1501 pin210
24 MDQ11 IC1481 pin79 IC1501 pin208
25 MDQ12 IC1481 pin80 IC1501 pin206
26 MDQ13 IC1481 pin82 IC1501 pin202
27 MDQ14 IC1481 pin83 IC1501 pin200
28 MDQ15 IC1481 pin85 IC1501 pin198
29 MDQ16 IC1481 pin31 IC1501 pin253
30 MDQ17 IC1481 pin33 IC1501 pin255
31 MDQ18 IC1481 pin34 IC1501 pin1
32 MDQ19 IC1481 pin36 IC1501 pin5
33 MDQ20 IC1481 pin37 IC1501 pin7
34 MDQ21 IC1481 pin39 IC1501 pin11
35 MDQ22 IC1481 pin40 IC1501 pin13
36 MDQ23 IC1481 pin42 IC1501 pin15
37 MDQ24 IC1481 pin45 IC1501 pin14
38 MDQ25 IC1481 pin47 IC1501 pin12
39 MDQ26 IC1481 pin48 IC1501 pin10
40 MDQ27 IC1481 pin50 IC1501 pin6
41 MDQ28 IC1481 pin51 IC1501 pin4
42 MDQ29 IC1481 pin53 IC1501 pin256
43 MDQ30 IC1481 pin54 IC1501 pin254
44 MDQ31 IC1481 pin56 IC1501 pin252
45 MCK IC1481 pin68 IC1501 pin223 0.17 Ω
or lower
46 XWE IC1481 pin17 IC1501 pin221
47 XCAS IC1481 pin18 IC1501 pin227
48 XRAS IC1481 pin19 IC1501 pin228
49 XCSM IC1481 pin20 IC1501 pin229
50 DQM0 IC1481 pin16 IC1501 pin219
51 DQM1 IC1481 pin71 IC1501 pin220
52 DQM2 IC1481 pin28 IC1501 pin250
53 DQM3 IC1481 pin59 IC1501 pin251
54 BA0 IC1481 pin22 IC1501 pin231
55 BA1 IC1481 pin23
IC1501 pin235
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
56 Ω 5 %
