Pioneer AVH-P7800DVD [27/280] Dvd mechanism module section parts list
![Pioneer AVH-P7800DVD [27/280] Dvd mechanism module section parts list](/views2/1616063/page27/bg1b.png)
AVH-P7800DVD/UC
27
5678
56
7
8
C
D
F
A
B
E
DVD MECHANISM MODULE SECTION PARTS LIST
Mark No. Description Part No.
1,2 •••••
3 DVD Core Unit CWX3300
4 •••••
5 Connector(CN1101) CKS4842
6 Connector(CN1301) CKS5017
7 Connector(CN1201) CKS5043
8 Connector(CN1851) CKS5045
9 Connector(CN1901) CKS5054
10 Screw BMZ20P020FTC
11 Screw(M2 x 3.5) CBA1571
12 Screw(M2 x 2.5) CBA1623
13 Screw CBA1787
14 Washer CBF1038
15 Washer CBF1064
16 Spring CBH2586
17 Spring CBH2588
18 Spring CBH2589
19 Spring CBH2590
20 Spring CBH2591
21 Spring CBH2592
22 Spring CBH2593
23 Spring CBH2595
24 Spring CBH2596
25 Spring CBH2597
26 Spring CBH2598
27 Spring CBH2599
28 Spring CBH2600
29 Spring CBH2601
30 Spring CBH2602
31 Spring CBH2604
32 Spring CBH2605
33 Spring CBH2710
34 Spring CBH2711
35 Spring CBH2876
36 Spring CBH2890
37 Spring CBH2895
38 Spring CBH2898
39 Shaft CLA4206
40 Shaft CLA4207
41 Shaft CLA4596
42 Lever CNC9933
43 Holder CNC9939
44 Frame CND2250
45 Holder CND2251
46 Holder CND2642
47 Sheet CNM6883
48 Sheet CNM8283
49 Sheet CNM9658
50 Cam CNV7156
51 Clamper CNV7158
52 Roller CNV7165
53 Rack CNV7175
54 Damper CNV7470
55 Damper CNV7471
56 Gear CNV8588
57 Holder CNV8765
58 Holder CNV8774
59 Collar CNV8845
60 Lever CNV8865
61 Rack CNV8866
62 Arm CNV8867
63 Arm CNV8868
64 Arm CNV8869
65 Arm CNV8870
66 Arm CNV8871
67 Arm CNV8872
68 Arm CNV8873
69 Gear CNV8874
70 Gear CNV8875
71 Gear CNV8876
72 Gear CNV8877
73 Gear CNV8878
74 Gear CNV8879
75 Gear CNV8880
76 Lever CNV8903
77 Lever CNV8904
78 Roller CNV8905
79 Lever CNV8908
80 Arm CNV8909
81 Guide CNV8910
82 Arm CNV9116
83 Arm CNV9117
84 Compound Unit(A) CWX3154
85 Compound Unit(B) CWX3394
86 Arm Unit CXB8681
87 Arm Unit CXB8683
88 Bracket Unit CXB8685
89 Chassis Unit CXC4910
90 Motor Unit(M1) CXC4912
91 Screw Unit CXC4979
92 Motor Unit(M2) CXC4980
93 Arm Unit CXC5486
94 Roller Unit CXC5708
95 Motor(M3) CXM1322
96 Screw JFZ20P018FTC
97 Washer YE20FTC
98 Screw Assy CXX1750
99 Pickup Unit(Service)(Screw) GXX1268
100 Screw IMS20P030FTC
101 Photo-transistor(Q1299) CPT231SCTD
102 Switch CSN1069
103 Switch CSN1070
104 Resistor RS1/16S0R0J
Mark
No. Description Part No.
