Pioneer AVH-P7800DVD [218/280] The cases where the displayed value eeprom written values and the register setting values in the double window ic are different are summarized below
![Pioneer AVH-P7800DVD [218/280] The cases where the displayed value eeprom written values and the register setting values in the double window ic are different are summarized below](/views2/1616063/page218/bgda.png)
AVH-P7800DVD/UC
218
1234
1234
C
D
F
A
B
E
[Line adjustment 2 menu]
[Setting content]
Note 1... Be careful as the displayed value (EEPROM written value) and the register setting values in
the double window IC
are different for the following items.
(Because the relationship between the double window IC register value and the screen output
value is not linear, there is a need for conversion by software.)
● YS sampling phase 1
● AD sampling phase B
● AD sampling phase G
● AD sampling phase R
● YS internal delay adjustment
Adjustment range
0-255DOT H POSITRGB & YS horizontal positioning(SA2B[D15-8]) 24
Initial value
Content
YS sampling phase 1(SA2D[D15-12]) YS SAMPL 0-15 8
AD sampling phase B(SA2D[D11-8]) B SAMPL 0-15 8
AD sampling phase G(SA2D[D7-4]) G SAMPL 0-15 8
AD sampling phase R(SA2D[D3-0]) R SAMPL 0-15 8
YS internal delay adjustment(SA2F[D3-0]) YS DELAY 0-15 8
Setting item
Displayed character string
The cases where the displayed value (EEPROM written values) and the register setting values in
the double window IC are different are summarized below.
[YS sampling phase 1, AD sampling phase B/G/R, YS internal delay adjustment]
[Line adjustment 3 menu]
[Setting content]
0 0 1000 (MIN)
1 1 1001
7 7 1111
8 8 0000 (TYP)
9 9 0001
:
:::
::
14 14 0110
15 15 0111 (MAX)
Displayed value (=adjusted value)
(DEC)
E2PROM written value
(DEC) (BIN)
Double window IC register value
Initial value
Content
Adjustment range
YS disp YS DISP 0-4 2
X disp X DISP 0-63 1
TH YS 0-4 3
Phase search threshold TH PHASE 0-255 112
Dot search threshold TH DOT 0-255 87
YS search threshold
Displayed character string
Setting item
[Line adjustment 4 menu]
[Setting content]
Adjustment range Initial value
Content
Main vertical enhancer corering(SA10[D3-2]) M V CORE 0-3 2
Main vertical enhancer return(SA10[D5-4]) M V ORI 0-3 2
Main vertical enhancer gain(SA10[D7-6]) M V GAIN 0-3 2
Main horizontal enhancer f0(SA10[D8]) M H F0 0-1 1
Main horizontal enhancer limiter(SA10[D11-10]) M H LIMIT 0-3 3
Main horizontal enhancer gain(SA10[D13-12]) M H GAIN 0-3 1
Displayed character string
Setting item
