![Pioneer AVH-P7800DVD [153/280] Circuit symbol and no part no](/img/pdf.png)
Pioneer AVH-P7800DVD [153/280] Circuit symbol and no part no
![Pioneer AVH-P7800DVD [153/280] Circuit symbol and no part no](/views2/1616063/page153/bg99.png)
AVH-P7800DVD/UC
153
5678
56
7
8
C
D
F
A
B
E
IC 1451 (A,100,29) IC TC7SZ126FU
IC 1452 (A,91,32) IC M5M5V216ATP-70HI
IC 1481 (B,48,36) IC EDS1232AATA-75
IC 1501 (A,45,48) IC MN2DS09AAUB
IC 1821 (B,16,47) IC PCM1753DBQ
IC 1822 (B,14,41) IC NJM2140R
IC 1823 (B,16,36) IC NJM2100V
IC 1851 (B,18,19) IC TC74VHC125FTS1
IC 1852 (B,15,27) IC TC74VHC125FTS1
IC 1853 (B,29,17) IC TC7SH08FUS1
Q 1002 (B,95,25) FET RSQ030P03
Q 1003 (B,103,24) FET QS5U27
Q 1101 (B,38,106) Transistor 2SB1260
Q 1102 (B,38,101) Transistor 2SB1260
Q 1106 (B,32,107) Transistor 2SC4081
Q 1107 (B,32,101) Transistor 2SC4081
Q 1801 (A,11,47) Transistor 2SA1576
Q 1802 (A,14,53) Transistor 2SA1576
Q 1803 (A,16,47) Transistor 2SA1576
Q 1804 (A,9,53) Transistor 2SA1576
D 1001 (B,104,14) Diode 1SR154-400
D 1002 (B,97,28) Diode RB050L-40
D 1005 (B,106,45) Diode 1SR154-400
D 1301 (B,14,86) LED CL205IRXTU
L 1001 (B,95,33) Inductor CTF1681
L 1002 (B,96,20) Inductor CTF1677
L 1003 (B,105,29) Inductor CTF1681
L 1004 (A,12,36) Inductor CTF1472
L 1005 (A,8,66) Inductor CTF1465
L 1006 (B,92,22) Inductor CTF1473
L 1101 (B,20,103) Inductor CTF1305
L 1401 (A,70,21) Inductor CTF1464
L 1451 (A,83,25) Inductor CTF1464
L 1481 (B,61,27) Inductor CTF1473
L 1501 (A,62,25) Inductor CTF1378
L 1502 (A,65,25) Inductor CTF1558
L 1503 (A,26,42) Inductor CTF1387
L 1504 (A,26,44) Inductor CTF1468
L 1509 (A,44,32) Inductor CTF1680
L 1601 (B,18,57) Inductor CTF1473
L 1602 (A,21,62) Inductor CTF1395
L 1603 (A,32,69) Inductor CTF1473
L 1604 (A,39,68) Inductor CTF1473
L 1605 (A,44,66) Inductor CTF1473
L 1671 (A,25,48) Inductor CTF1473
L 1672 (A,25,50) Inductor CTF1473
L 1673 (A,22,56) Inductor CTF1473
L 1801 (A,9,43) Inductor CTF1473
L 1822 (B,20,43) Inductor CTF1473
L 1851 (B,21,27) Inductor CTF1473
L 1852 (B,20,14) Inductor CTF1381
L 1853 (B,16,14) Inductor CTF1467
L 1854 (B,10,26) Inductor CTF1467
L 1855 (B,18,23) Inductor CTF1467
L 1856 (B,15,22) Inductor CTF1467
L 1901 (A,110,48) Inductor CTF1487
L 1902 (B,99,12) Inductor CTF1558
L 1903 (B,96,14) Inductor CTF1468
X 1501 (B,31,51) Resonator 27.000 MHz CSS1697
VR1671 (A,21,51) Semi-fixed 10 kΩ(B) CCP1448
Circuit Symbol and No. Part No.
EF1401 (A,73,21) EMI Filter DTL1106
EF1501 (A,62,28) EMI Filter DTL1106
EF1502 (A,65,28) EMI Filter DTL1106
EF1901 (A,107,49) EMI Filter DTF1106
EF1902 (B,93,14) EMI Filter DTL1106
EF1903 (B,99,15) EMI Filter DTL1106
RESISTORS
R 1001 (B,84,35) RS1/16SS4702D
R 1002 (B,85,36) RS1/16SS103J
R 1003 (B,83,33) RS1/16SS221J
R 1004 (B,82,31) RS1/16SS101J
R 1005 (B,87,35) RS1/16SS153J
R 1007 (B,84,33) RS1/16SS1002D
R 1008 (B,84,31) RS1/16SS331J
R 1009 (B,88,33) RS1/16SS471J
R 1010 (B,85,33) RS1/16SS472J
R 1011 (B,88,24) RS1/16SS273J
R 1013 (B,80,31) RS1/16SS472J
R 1014 (B,79,31) RS1/16SS2202D
R 1015 (B,79,33) RS1/16SS102J
R 1017 (B,66,21) RS1/10S330J
R 1020 (B,78,33) RS1/16SS101J
R 1021 (B,77,40) RS1/16SS104J
R 1022 (B,93,27) RS1/16SS100J
R 1023 (B,102,21) RS1/16SS100J
R 1024 (B,80,29) RS1/16SS1002D
R 1101 (B,28,105) RS1/16SS6R8J
R 1102 (B,26,106) RS1/10S1R5J
R 1103 (B,23,107) RS1/10S1R5J
R 1104 (B,24,110) RS1/10S1R5J
R 1105 (B,26,108) RS1/10S1R5J
R 1106 (B,28,98) RS1/16SS6R8J
R 1107 (B,26,101) RS1/10S1R5J
R 1108 (B,23,102) RS1/10S1R5J
R 1109 (B,24,105) RS1/10S1R5J
R 1110 (B,26,103) RS1/10S1R5J
R 1114 (B,28,107) RS1/16SS391J
R 1115 (B,28,101) RS1/16SS391J
R 1116 (B,35,106) RS1/16SS511J
R 1117 (B,35,101) RS1/16SS561J
R 1118 (A,50,72) RS1/16SS104J
R 1119 (B,31,96) RS1/16SS104J
R 1120 (B,30,95) RS1/16SS104J
R 1203 (A,27,78) RS1/16SS2R7J
R 1204 (A,27,79) RS1/16SS2R7J
R 1205 (A,27,80) RS1/16SS2R7J
R 1206 (A,27,81) RS1/16SS2R7J
R 1207 (A,23,89) RS1/16SS221J
R 1208 (A,21,89) RS1/16SS221J
R 1213 (A,27,82) RS1/16SS2R7J
R 1214 (A,27,75) RS1/16SS151J
R 1215 (A,27,83) RS1/16SS2R7J
R 1216 (A,27,77) RS1/16SS2R7J
R 1217 (A,24,89) RS1/16SS103J
R 1219 (A,29,83) RS1/16SS2R7J
R 1220 (A,13,91) RS1/16SS1R0J
R 1221 (A,13,92) RS1/16SS1R0J
R 1222 (A,30,83) RS1/16SS2R7J
