L 5136 (A,102,94) Inductor VTL1133
L 5137 (A,103,94) Inductor VTL1126
L 5138 (A,105,92) Inductor CTF1386
L 5139 (A,108,93) Inductor VTL1133
L 5140 (A,108,91) Inductor CTF1547
L 5141 (A,85,94) Inductor VTL1133
L 5142 (A,87,94) Inductor VTL1133
L 5143 (A,89,94) Inductor VTL1133
L 5144 (A,93,94) Inductor VTL1133
L 5145 (A,96,94) Inductor VTL1133
L 5146 (A,98,94) Inductor VTL1133
L 5147 (A,101,94) Inductor VTL1133
L 5148 (A,92,94) Inductor VTL1133
L 5149 (A,95,94) Inductor VTL1133
L 5150 (A,97,94) Inductor VTL1133
L 5151 (A,99,94) Inductor VTL1133
L 5152 (A,95,92) Inductor CTF1306
L 5153 (A,99,92) Inductor CTF1306
L 5154 (A,102,92) Inductor CTF1306
L 5155 (A,89,92) Inductor CTF1306
L 5156 (A,92,92) Inductor CTF1306
L 5157 (A,83,92) Inductor CTF1306
L 5158 (A,86,92) Inductor CTF1306
L 5163 (A,88,51) Inductor CTF1306
L 5165 (A,91,50) Inductor LCTAW220J2520
L 5167 (A,111,66) VTL1127
L 5170 (A,80,54) Inductor CTF1635
L 5171 (A,114,94) Inductor CTF1635
L 5172 (A,87,47) Inductor CTF1635
L 5173 (A,113,58) Inductor CTF1635
L 5174 (A,114,65) Inductor CTF1635
L 5175 (A,115,89) Inductor CTF1635
L 5201 (A,113,99) Inductor CTF1306
L 5202 (A,62,84) Inductor LCKAW101J2520
L 5203 (A,78,89) Inductor LCKAW101J2520
L 5204 (A,76,92) Inductor CTF1306
L 5301 (A,122,110) Inductor CTF1306
L 5302 (A,73,95) Inductor DTL1096
L 5303 (A,111,109) Inductor CTF1306
L 5304 (A,75,97) Inductor DTL1096
L 5402 (A,73,61) Inductor CTF1473
L 5403 (A,62,55) Inductor CTF1473
L 5404 (A,58,65) Inductor VTL1127
T 5501 (B,70,10) Transformer CTT1130
TH4001 (A,56,100) Thermistor CCX1063
X 4001 (A,57,89) Radiator 8.0 MHz CSS1675
X 4301 (A,14,57) Radiator 24.800 MHz CSS1700
X 5101 (A,86,57) Crystal Resonator 42 MHz CSS1604
X 5401 (A,55,57) Radiator 33.231 MHz CSS1702
S 4501 (B,97,12) Push Switch CSG1155
S 4502 (B,110,12) Push Switch CSG1155
S 4503 (B,123,12) Push Switch CSG1155
VR5501 (A,76,24) Semi-fixed 15 kΩ(B) CCP1490
>FU5001 (A,135,57) Fuse 750 mA CEK1279
>FU5501 (A,87,38) Fuse 1.75 A CEK1283
FB4201 (A,36,35) Inductor CTF1639
FB4202 (A,29,29) Inductor CTF1639
FB4204 (A,40,32) Inductor CTF1639
FB4205 (A,40,23) Inductor CTF1639
FB4203 (A,29,26) Inductor CTF1639
Circuit Symbol and No. Part No.
FB4206 (A,29,23) Inductor CTF1639
FB5303 (A,67,95) Inductor CTF1635
FB5301 (A,79,92) Inductor CTF1635
FB5001 (A,143,94) Inductor CTF1635
FB5003 (A,137,96) Inductor CTF1635
FB5302 (A,113,104) Inductor CTF1635
FB5002 (A,125,56) Inductor CTF1635
EF4201 (A,50,36) EMI Filter DTL1106
EF4301 (A,52,47) EMI Filter DTL1106
RESISTORS
R 4001 (A,55,75) RS1/16SS473J
R 4002 (A,57,73) RS1/16SS473J
R 4003 (A,55,74) RS1/16SS473J
R 4004 (A,57,71) RS1/16SS473J
R 4007 (A,53,73) RS1/16SS471J
R 4008 (A,55,76) RS1/16SS473J
R 4009 (A,58,79) RS1/16SS471J
R 4010 (A,53,72) RS1/16SS471J
R 4011 (A,55,72) RS1/16SS470J
R 4012 (A,55,73) RS1/16SS470J
R 4013 (A,53,75) RS1/16SS470J
R 4014 (A,53,76) RS1/16SS470J
R 4015 (A,53,74) RS1/16SS470J
R 4017 (A,28,77) RAB4CQ221J
R 4018 (A,56,80) RS1/16SS470J
R 4019 (A,56,81) RS1/16SS471J
R 4020 (A,58,80) RS1/16SS470J
R 4021 (A,28,80) RAB4CQ221J
R 4022 (A,56,82) RS1/16SS471J
R 4023 (A,56,83) RS1/16SS470J
R 4024 (A,58,82) RS1/16SS470J
R 4025 (A,28,84) RAB4CQ221J
R 4026 (A,56,85) RS1/16SS221J
R 4027 (A,56,86) RS1/16SS221J
R 4028 (A,28,87) RAB4CQ221J
R 4029 (A,56,87) RS1/16SS473J
R 4030 (A,58,86) RS1/16SS220J
R 4031 (A,59,86) RS1/16SS220J
R 4032 (A,29,91) RAB4CQ221J
R 4033 (A,61,108) RS1/16SS124J
R 4034 (A,28,94) RAB4CQ221J
R 4035 (A,58,92) RS1/16SS473J
R 4036 (A,58,93) RS1/16SS473J
R 4037 (A,55,93) RS1/16SS102J
R 4038 (A,28,97) RS1/16SS151J
R 4039 (A,34,104) RS1/16SS473J
R 4040 (A,53,102) RS1/16SS102J
R 4041 (A,45,102) RS1/16SS473J
R 4042 (A,42,102) RS1/16SS473J
R 4043 (A,43,100) RS1/16SS473J
R 4044 (A,31,101) RS1/16SS221J
R 4045 (A,32,101) RS1/16SS221J
R 4046 (A,34,101) RS1/16SS471J
R 4047 (A,35,101) RS1/16SS151J
R 4048 (A,36,101) RS1/16SS151J
R 4049 (A,37,103) RS1/16SS473J
R 4050 (A,57,96) RS1/16SS473J
R 4053 (A,24,113) RS1/16SS103J
Circuit Symbol and No. Part No.
