Pioneer AVH-P7800DVD [171/280] Unit number cwn1549 unit name amp unit
![Pioneer AVH-P7800DVD [171/280] Unit number cwn1549 unit name amp unit](/views2/1616063/page171/bgab.png)
AVH-P7800DVD/UC
171
5678
56
7
8
C
D
F
A
B
E
C 8766 (A,83,63) CEVW221M4
C 8768 (B,127,22) CKSRYB104K25
C 8769 (B,146,28) CCSRCH121J50
C 8770 (A,50,25) CCSRCH121J50
C 8771 (B,88,23) CKSRYB105K10
C 8772 (B,90,25) CKSRYB105K10
C 8801 (B,76,35) CKSRYB102K50
C 8802 (B,76,38) CKSRYB102K50
C 8901 (A,72,60) 10 µF CCG1171
C 8902 (A,70,60) 10 µF CCG1171
C 8903 (A,68,60) 10 µF CCG1171
C 8904 (A,66,60) 10 µF CCG1171
C 8905 (A,63,60) 10 µF CCG1171
C 8906 (A,61,60) 10 µF CCG1171
C 8907 (A,77,55) CKSRYB104K25
C 8908 (A,71,55) CKSRYB104K25
C 8909 (A,64,55) CKSRYB104K25
C 8911 (A,74,51) CKSRYB105K10
C 8913 (B,65,52) CKSRYB105K10
C 8914 (A,61,52) CKSRYB105K10
C 8916 (A,58,42) CEVW470M10
C 8917 (A,67,50) CKSRYB104K25
C 8918 (A,67,37) CKSRYB104K25
C 8919 (A,75,44) CKSRYB104K25
C 8920 (A,71,37) CKSRYB104K25
C 8921 (A,73,25) 22 µF CCG1178
C 8922 (A,66,25) 22 µF CCG1178
C 8923 (A,58,25) 22 µF CCG1178
C 8924 (A,73,30) CEVW101M6R3
C 8925 (A,65,30) CEVW101M6R3
C 8926 (A,58,30) CEVW101M6R3
C 8928 (B,75,53) CKSRYB103K50
C 8929 (B,58,47) CKSRYB103K50
C 8932 (B,61,50) CKSRYB103K50
C 8933 (B,70,42) CKSRYB103K50
C 8934 (B,68,42) CKSRYB103K50
C 8935 (B,61,42) CKSRYB103K50
J
Unit Number: CWN1549
Unit Name : Amp Unit
MISCELLANEOUS
IC 9021 (A,23,109) IC AN8015SH
IC 9101 (A,21,28) IC OPA2134UA
IC 9102 (A,36,28) IC OPA2134UA
IC 9151 (A,36,38) IC OPA2134UA
IC 9171 (A,21,38) IC OPA2134UA
IC 9181 (A,55,28) IC OPA2134UA
IC 9202 (A,25,70) IC PM9009A
IC 9251 (A,25,51) IC PM9009A
IC 9321 (A,48,54) IC PAL007B
IC 9322 (A,48,116) IC PAL007B
Q 9001 (A,31,132) Transistor 2SD1664
Q 9011 (B,76,134) Transistor UMF5N
Q 9012 (B,70,126) Transistor 2SD1760F5
Q 9021 (A,32,124) DTC124EUA
Q 9022 (A,27,126) Transistor 2SA1797
Q 9023 (A,21,115) Transistor UMZ1N
Circuit Symbol and No. Part No.
Q 9024 (A,13,110) Transistor 2SA1797
Q 9025 (A,30,104) Transistor DTC124EUA
Q 9051 (B,44,92) Transistor DTC124EUA
Q 9052 (B,44,96) Transistor 2SA1576
Q 9054 (B,38,89) Transistor DTA114EU
Q 9055 (B,34,99) Transistor 2SC4081
Q 9056 (A,22,139) Transistor 2SC4081
Q 9061 (B,19,145) Transistor DTC124EUA
Q 9062 (B,24,145) Transistor DTC124EUA
Q 9441 (A,67,20) Transistor IMX9
Q 9442 (A,52,20) Transistor IMX9
Q 9443 (A,37,20) Transistor IMX9
Q 9444 (A,22,20) Transistor IMX9
Q 9445 (A,14,20) Transistor IMX9
Q 9446 (A,74,20) Transistor IMX9
Q 9447 (A,59,20) Transistor IMX9
Q 9448 (A,44,20) Transistor IMX9
Q 9449 (A,29,20) Transistor IMX9
Q 9451 (B,25,135) DTA144EUA
D 9001 (A,25,132) Diode UDZS18(B)
D 9002 (A,47,157) Diode 1SR154-400
D 9003 (A,43,157) Diode 1SR154-400
D 9004 (A,43,164) Diode 1SR154-400
D 9005 (A,47,164) Diode 1SR154-400
D 9011 (B,78,129) Diode HZU6R8(B3)
D 9021 (A,12,104) Diode SC802-06
D 9051 (B,22,138) Diode DAN202U
D 9052 (B,33,85) Diode HZU7R5(B3)
D 9053 (B,29,136) Diode DAN202U
D 9202 (A,14,71) Diode RB751V-40
D 9251 (A,14,51) Diode RB751V-40
D 9451 (B,29,155) Diode DAN202U
D 9452 (B,21,155) Diode DAN202U
L 9021 (A,14,117) Coil CTH1267
L 9022 (A,17,104) Coil CTH1267
L 9023 (A,14,86) Coil CTH1267
L 9024 (A,9,82) Inductor CTF1379
L 9025 (A,18,112) Chip Coil LCTAW100J2520
L 9202 (B,11,73) Inductor LCYC2R2K2125
L 9251 (B,11,59) Inductor LCYC2R2K2125
L 9401 (B,74,17) Inductor CTF1473
L 9402 (B,67,17) Inductor CTF1473
L 9403 (B,60,17) Inductor CTF1473
L 9404 (B,52,17) Inductor CTF1473
L 9405 (B,46,17) Inductor CTF1473
L 9406 (B,39,17) Inductor CTF1473
L 9407 (B,32,17) Inductor CTF1473
L 9408 (B,24,17) Inductor CTF1473
L 9441 (B,17,17) Inductor CTF1473
L 9442 (A,80,21) Inductor CTF1487
L 9451 (A,11,129) Inductor CTF1379
VR9021 (A,26,101) Semi-fixed 10 kΩ(B) CCP1396
>FU9011 (A,72,141) Fuse 1.5 A CEK1282
>FU9012 (A,72,29) Fuse 1.5 A CEK1282
>FU9021 (A,9,85) Fuse 0.5 A CEK1278
>FU9441 (A,80,27) Fuse 3 A CEK1286
>FU9451 (A,45,169) Fuse 3 A CEK1286
RESISTORS
Circuit Symbol and No. Part No.
