EXTERIOR(3) SECTION PARTS LIST
Mark No. Description Part No.
1 Drive Unit CXC6161
2 Screw AMZ26P030FTC
3 Screw(M2 x 1.4) CBA2025
4 Screw(M2 x 2) CBA1871
5 Screw(M2 x 2.5) CBA2026
6 Washer CBF1039
7 Spring CBH2905
8 Spring CBL1718
9 Cord CDE8121
10 Gear CND3231
11 Gear CND3232
12 Insulator CNN1060
13 Spacer CNN1258
14 Gear CNR1853
15 Guide CNV8954
16 Guide CNV8955
17 Guide CNV8956
18 Gear CNV8974
19 Gear CNV8975
20 Holder Unit CXC6076
21 Case Unit CXC6118
22 Bracket Unit CXC6121
23 Motor Unit CXC6122
24 Arm Unit CXC6123
25 Arm Unit CXC6124
26 Frame Unit CXC6125
27 Frame Unit CXC6126
28 Screw JGZ20P025FTC
29 Washer YE30FTC
30 Button CAC9682
31 Button CAC9683
32 Button CAC9684
33 Screw CBA1872
34 Cushion CNN1259
35 Lighting Conductor CNV8959
36 Lighting Conductor CNV8960
37 LCD(LCD7001) CAW1921
38 Connector(CN7401) CKS5502
39 Holder CND3214
40 Sheet CNM9990
41 Spacer CNN1257
42 Lighting Conductor CNV8965
43 Connector CNV8966
44 Knob Unit CXC6077
45 Spring CBL1721
46 Grille Unit CXC7165
47 Cover Unit CXC7171
48 •••••
49 Button Unit CXC6641
50 Spring CBL1733
51 Grille Assy CXC5656
52 Screw(M2 x 2) CBA1871
53 Screw CBA2009
54 Guide CNV8957
55 Bracket Assy CXC6106
56 Bracket Assy CXC6107
57 Panel Unit CXC7164
58 Flexible PCB CNP9204
59 DVD Mechanism Module(MS-4) CXK6500
60 Bracket CND3213
61 Screw BMZ20P030FTB
62 Screw IMS26P030FTB
63 Sheet CNN1262
64 Flexible PCB CNP9258
65 Guide CNV9015
66 Screw(M2 x 2) CBA1872
67 Sheet CNN1435
68 Screw TMS26P030FTC
69 Spring CBH2953
70 Connector CKS5503
