Pioneer AVH-P7800DVD [15/280] Exte rior 2 section parts list
![Pioneer AVH-P7800DVD [15/280] Exte rior 2 section parts list](/views2/1616063/page15/bgf.png)
AVH-P7800DVD/UC
15
5678
56
7
8
C
D
F
A
B
E
EXTE-
RIOR(2) SECTION PARTS LIST
Mark
No. Description Part No.
1 Drive Unit CXC6148
2 Screw(M2 x 2) CBA1608
3 Screw(M2 x 1.5) CBA1615
4 Screw(M2 x 2) CBA1872
5 Screw(M2 x 3) CBA1877
6 Screw CBA2027
7 Washer CBF1037
8 Washer CBF1039
9 Washer CBF1064
10 Spring CBH2906
11 Spring CBH2907
12 Spring CBH2908
13 Spring CBH2909
14 Spring CBL1723
15 Spring CBL1734
16 Cord CDE8127
17 Cord CDE8128
18 Shaft CLA4651
19 Shaft CLA4661
20 Shaft CLA4662
21 Shaft CLA4663
22 Shaft CLA4664
23 Shaft CLA4665
24 Shaft CLA4666
25 Holder CND3245
26 Cover CND3252
27 Sheet CNN1055
28 Sheet CNN1056
29 Insulator CNN1057
30 Insulator CNN1058
31 Sheet CNN1065
32 Insulator CNN1068
33 Gear CNR1855
34 Gear CNR1856
35 Gear CNR1857
36 Gear CNR1858
37 Gear CNR1859
38 Gear CNR1860
39 Gear CNR1861
40 Gear CNR1862
41 Gear CNR1864
42 Gear CNR1865
43 Gear CNV8980
44 Gear CNV8981
45 Gear CNV8983
46 Gear CNV8984
47 Gear CNV8985
48 Gear CNV8987
49 Rack CNV8995
50 Rack CNV8996
51 Guide CNV8997
52 Guide CNV8998
53 Guide CNV8999
54 Lever CNV9000
55 Arm CNV9001
56 Guide CNV9003
57 Guide CNV9004
58 Chassis Unit CXC6142
59 Frame Unit CXC6143
60 Case Unit CXC6144
61 Holder Unit CXC6145
62 Motor Unit CXC6638
63 Screw JGZ20P025FTC
64 Motor Unit CXC6639
65 Screw JGZ20P025FTC
66 Screw JFZ17P025FTC
67 Washer YE15FTC
68 Screw(M2 x 3) CBA1797
69 Screw CBA2041
70 Spring CBH2750
71 Spring CBL1720
72 Lever CND3250
73 Cover CNV9002
74 Arm CNV9005
75 Panel CNV9008
76 Panel CNV9009
77 Bracket Unit CXC6147
78 Main PCB Unit CZW5027
* 79 Volume PCB Unit CZW5028
* 80 Switch PCB Unit CZW5029
* 81 Insulator CNN1349
Mark
No. Description Part No.
