TUNER SELECTOR ASSY SECTION PARTS LIST
Mark No. Description Part No.
1 Screw ASZ26P050FTC
2 Screw BMZ20P160FTC
3 Screw BSZ30P060FTB
4 Flat Cable CDE8100
5 Chassis CNA2889
6 Case CNB3259
7 Insulator CNM9984
8 Insulator CNN1313
9 Tuner Selector Unit CWN1536
10 Screw BMZ30P080FTC
11 Screw BPZ30P060FTC
12 Pin Jack(CN8251) CKB1076
13 Pin Jack(CN8751) CKB1078
14 Plug(CN8701) CKS-464
15 Connector(CN8201) CKS2602
16 Connector(CN8451) CKS4590
17 •••••
18 Connector(CN8401) CKS5066
19 Connector(CN8901) CKS5497
20 Connector(CN8601) CKS5500
21 Antenna Jack(CN8502) CKX1056
22 Holder CNC9888
23 Holder CND3202
24 Holder CND3204
25 Shield CND3206
26 Holder CND3437
27 Insulator CNM9521
28 Insulator CNN1356
29 Heat Sink CNR1879
30 FM/AM Tuner Unit(Y8501) CWE1806
31 Connector(CN101) CKS4653
32 Connector(CN102) CKS4653
33 Holder CND2145
34 Amp Unit CWN1549
35 Screw BMZ26P200FTC
36 Screw BPZ30P060FTC
37 Clamper CEF1042
38 Pin Jack(CN9443) CKB1073
39 Pin Jack(CN9442) CKB1074
40 Pin Jack(CN9441) CKB1077
41 Socket(CN9001) CKM1446
42 Connector(CN9011) CKS4822
43 Connector(CN9012) CKS4822
44 Connector(CN9452) CKS5066
45 Connector(CN9451) CKS5560
46 Holder CND3198
47 Holder CND3199
48 Holder CND3200
49 Heat Sink CNR1852
50 Motor CXM1246
51 IC(IC9321,IC9322) PAL007B
52 IC(8504) NJM2388F84
