AVH-P7800DVD/UC
208
1234
1234
C
D
F
A
B
E
Unit
Name
Signal input
point
Input signal Input
level
Measuring
point
Spec.
Adjusting
point
1
Mother
unit
TP733 Component Y signal 1 Vp-p TP573 1 Vp-p
VR511
100% color bar
(Fig.1)
2
TP734 Component Pb signal
700 mVp-p
TP572 700 mVp-p
VR512
100% color bar
(Fig.2)
3
TP735 Component Pr signal
700 mVp-p
TP574 700 mVp-p
VR513
100% color bar
(Fig.3)
4
TP733 Component Y signal 1 Vp-p CN751 pin16 1 Vp-p
VR451
100% color bar (75 Ω
Receipt)
*1
5
TP734 Component Pb signal
700 mVp-p
CN751 pin12 700 mVp-p
VR452
100% color bar (75 Ω
Receipt)
*1
6
TP735 Component Pr signal
700 mVp-p
CN751 pin8 700 mVp-p
VR453
100% color bar (75 Ω
Receipt)
*1
(75 Ω
Receipt)
*1
(75 Ω
Receipt)
*1
(75 Ω
Receipt)
*1
7
TP731 Composite signal 1 Vp-p TP571 0.75 Vp-p
VR491
white 100% (100 IRE)
8
TP731 Composite signal 1 Vp-p TP451 2 Vp-p
VR281
white 100% (100 IRE)
9
Tuner
selector
unit
MS4Y Component Y signal 1 Vp-p TP_YOUT 1 Vp-p
VR8901
100% color bar
(CN8901 pin2)
(75 Ω output) *2
10
MS4BC Component Pb signal
700 mVp-p
TP_CBOUT 700 mVp-p
VR8902
100% color bar
(CN8901 pin4)
(75 Ω output) *2
11
MS4CR Component Pr signal
700 mVp-p
TP_CROUT 700 mVp-p
VR8903
100% color bar
(CN8901 pin6)
(75 Ω output) *2
12
TP_TVVBS Composite signal 1 Vp-p FCOMP 2 Vp-p
VR8751
white 100% (100 IRE)
13
TP_TVVBS Composite signal 1 Vp-p TP_REARV 1 Vp-p
VR8752
white 100% (100 IRE)
(CN8251 pin9)
(75 Ω
Receipt)
*1
*1 : (75 Ω Receipt) which is a spec. In a certain case, please adjust
with the value lowered to the standard value side 75 Ω.
*2 : In (75 Ω output) and a certain case, an incoming signal should
be set to an input level in the state at the column of an incoming signal.
Video level adjustment
