91
A
A
Printer specifications A
Engine A
1
The printing speed may change depending on the type of document you print.
2
From standard paper tray.
Controller A
1
Compatible with USB 2.0 specification
2
See the Network User's Guide locator on the CD-ROM for details on the supported network protocols.
3
Code39, Interleaved 2 of 5, EAN-8, EAN-13, UPC-A, UPC-E, EAN-128, Codabar, FIM (US-PostNet), ISBN, Code128
Appendix A
Model SP 1210N
Technology Electrophotographic
Print speed
12
(A4 size/ Letter size)
Up to 22 ppm (A4 size)
2
,Up to 23 ppm (Letter size)
2
Resolution
Windows
®
2000/XP/
XP Professional x64
Edition,
Windows Vista
®
,
Windows
®
7,
Windows Server
®
2003/
Windows Server
®
2003 x64 Edition
HQ1200
600 dpi
300 dpi
DOS 600 dpi
Model SP 1210N
Processor 181MHz
Memory 16 MB
Interface
USB
1
,
10BASE-T/100BASE-TX Ethernet
Network
Connectivity
Protocols
TCP/IP (Standard 10/100BASE-TX Ethernet)
2
Management tool BRAdmin Light
Emulation PCL6
Resident fonts PCL
49 scalable fonts, 12 bitmap fonts, 11 bar codes
3
