Appendix (for USA and Canada)
112
C
Important Information for Australia C
IMPORTANT-For Your Safety C
To ensure safe operation the three-pin plug supplied must be inserted only into a standard three-pin power
point which is effectively grounded through the normal household wiring.
Extension cords used with the equipment must be three-conductor and be correctly wired to provide
connection to ground. Incorrectly wired extension cords are a major cause of fatalities.
The fact that the equipment operates satisfactorily does not imply that the power is grounded and that the
installation is completely safe. For your safety, if in any doubt about the effective grounding of the power,
consult a qualified electrician.
Important safety instructions C
1 Read all of these instructions.
2 Save them for later reference.
3 Follow all warnings and instructions marked on the product.
4 Unplug this product from the wall socket before cleaning the outside of the machine and the scanner glass.
DO NOT use liquid or aerosol cleaners. Use a damp cloth for cleaning.
5 DO NOT use this product near water.
6 DO NOT place this product on an unstable cart, stand, or table. The product may fall, causing serious
damage to the product.
7 Slots and openings in the casing at the back or bottom are provided for ventilation; to ensure reliable
operation of the product and to protect it from overheating, these openings must not be blocked or covered.
The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should never be placed near or over a radiator or heater. This product should never be placed
in a built-in installation unless adequate ventilation is provided.
8 This product should be connected to an AC power source within the range indicated on the rating label.
DO NOT connect it to a DC power source or inverter. If you are not sure, contact a qualified electrician.
9 This product is equipped with a 3-wire grounded plug, a plug having a third (grounded) pin. This plug will
only fit into a grounded power outlet. This is a safety feature. If you are unable to insert the plug into the
outlet, call your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounded
plug.
10 DO NOT place anything on top of the power cord including this machine. DO NOT allow the power cord
to be stepped on.
11 DO NOT touch a document during printing.
12 Never push objects of any kind into this product through cabinet slots, since they may touch dangerous
voltage points or short out parts resulting in a risk of fire or electric shock. Never spill liquid of any kind on
the product.
13 DO NOT attempt to service this product yourself, because opening or removing covers may expose you
to dangerous voltage points and/or other risks. Refer all servicing to service personnel.
