Appendix (for USA and Canada)
114
C
Important Information for Some Countries C
Important Safety Instructions C
1 Read all of these instructions.
2 Save them for later reference.
3 Follow all warnings and instructions marked on the product.
4 Unplug this product from the wall outlet before cleaning the outside of the machine and the scanner glass.
DO NOT use liquid or aerosol cleaners. Use a damp cloth for cleaning.
5 DO NOT place this product near water.
6 DO NOT place this product on an unstable cart, stand, or table. The product may drop, causing serious
damage to the product.
7 Slots and openings in the casing at the back or bottom are provided for ventilation; to ensure reliable
operation of the product and to protect it from overheating, these openings must not be blocked or covered.
The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should never be placed near or on a radiator or heater. This product should never be placed
in a built-in installation unless adequate ventilation is provided.
8 This product should be connected to an AC power source within the range indicated on the rating label.
DO NOT connect it to a DC power source or inverter. If you are not sure, contact a qualified electrician.
9 This product is equipped with a 2-wire grounding type plug or a 3-wire grounding type plug (Only for
Singapore, Malaysia, Hong Kong and India), a plug having two or three pins. This plug will only fit into only
a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounding-type
plug.
10 DO NOT place anything on top of the power cord including this machine. DO NOT allow the power cord
to be stepped on.
11 If an extension cord is used with this product, make sure that the total ampere ratings on the products
plugged into the extension cord DO NOT exceed the extension cord ampere rating.
12 DO NOT touch a document during printing.
13 Never push objects of any kind into this product through cabinet slots, since they may touch dangerous
voltage points or short out parts resulting in the risk of fire or electric shock. Never spill liquid of any kind
on the product.
14 DO NOT attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage points and/or other risks, and may void your warranty. Please refer all servicing to our
Authorized Service Personnel.
15 Unplug this product from the wall outlet and refer servicing to Authorized Service Personnel under the
following conditions:
If the power cord is damaged or frayed.
If the product has been spilled by liquid.
If the product has been exposed to rain or water.
