Ricoh Aficio SP 1210N [99/129] Network problems

Troubleshooting

Network problems 6

For problems concerning using your printer on a Network, see the Network User’s Guide on the CD-ROM we

have supplied. Click Documentation on the menu screen.

The Network User’s Guide in PDF format will be installed automatically when you install the driver. Click the

Start button, All Programs

, your printer, and then User’s Guide.

Programs for Windows

2000 users
