Ricoh Aficio SP 1210N [5/129] Symbols for the main power switch

CAUTION

Be sure to disconnect the plug from the wall outlet and clean the prongs and the area around the prongs at

least once a year.

Allowing dust to build up on the plug constitutes a fire hazard.

Symbols for the main power switch

In accordance with IEC 60417, this machine uses the following symbols for the main power switch:

means POWER ON.

means POWER OFF.
