Ricoh Aficio SP 1210N [101/129] Control panel
![Ricoh Aficio SP 1210N [101/129] Control panel](/views2/1064328/page101/bg65.png)
Appendix
92
A
Software A
1
Instructional animations for problem solving.
Control panel A
Paper handling A
1
Calculated with 80 g/m2 (20 lb) paper
2
For A4, LT size
Media specifications A
1
Up to 10 sheets
2
Legal size paper is not available in some regions outside the USA and Canada.
Model SP 1210N
Printer driver
Windows
®
PCL printer driver for Windows
®
2000/XP/XP Professional x64 Edition, Windows
Vista
®
, Windows Server
®
2003/Windows Server
®
2003 x64 Edition
Utilities
Interactive Help
1
Model SP 1210N
LED 4 LEDs
Button 1 button
Model SP 1210N
Paper Input
1
Manual feed slot 1 sheet
Paper tray 250 sheets
Paper
Output
1
Face-down
100 sheets
2
Face-up 1 sheet
Duplex Manual Duplex
Model SP 1210N
Media types Manual feed slot Plain paper, Bond paper, Recycled paper, Thin paper, Thick paper,
Envelopes, Labels, Transparencies
Paper tray
Plain paper, Recycled paper, Thin paper, Transparencies
1
Media
weights
Manual feed slot
60 to 163 g/m
2
(16 to 43 lb)
Paper tray
60 to 105 g/m
2
(16 to 28 lb)
Media sizes Manual feed slot Width: 76.2 to 220mm (3.0 to 8.66 in.)
Length: 116 to 406.4 mm (4.57 to 16 in.)
Paper tray (Standard)
A4, Letter, Legal
2
, B5 (ISO), Executive, A5, A6, B6, Folio
