Ricoh Aficio SP 1210N [60/129] Routine maintenance

You will need to replace certain parts and clean the printer regularly.

WARNING

When you replace certain parts or clean the inside of the printer, remember the following:

• If your clothes are smeared with toner, wipe off the toner with a dry cloth and immediately wash the

clothes in cold water to avoid stains.

• Be careful not to inhale toner.

• After you have just used the printer, some internal parts of the printer will be extremely hot. To prevent

injury, when you open the front cover or back cover (back output tray) of the printer, DO NOT touch the

shaded parts shown in the illustration.

Routine Maintenance 5
