Ricoh Aficio SP 1210N [61/129] Replacing the consumable items

Routine Maintenance

Replacing the consumable items 5

You will need to replace the consumable items when the machine indicates that the life of the consumable is

over.

Consumables 5

Approx. cartridge yield is declared in accordance with ISO/IEC 19752.

Toner cartridge Drum unit

See Toner cartridge on page 53.

Print Cartridge SP 1200E (for Europe)

Print Cartridge SP 1200A (USA and Canada)

Print Cartridge SP 1200S (For Asia)

(Approx. 2,600 pages A4/Letter pages)

See Drum unit on page 60.

Drum Unit SP 1200

(Approx. 12,000 pages A4/Letter pages)
