Ricoh Aficio SP 1210N [90/129] Push down the green lock lever and take the toner cartridge out of the drum unit clear the jammed paper if there is any inside the drum unit

Troubleshooting

j Push down the green lock lever and take the toner cartridge out of the drum unit. Clear the jammed paper

if there is any inside the drum unit.

CAUTION

Handle the toner cartridge carefully. If toner scatters on your hands or clothes, wipe or wash it off with cold

water at once.

To avoid print quality problems, DO NOT touch the shaded parts shown in the illustrations.
