Ricoh Aficio SP 1210N [12/129] Back view

About this Printer

Back view 1

1 Back cover (back output tray)

2 AC power connector

3 Network status LEDs (Light Emitting Diodes)

4 10/100BASE-TX port

5 USB interface connector
