Printing Methods
19
2
Note
• When you use Envelope #10, choose Com-10 for the Paper Size.
• For other envelopes which are not listed in the printer driver, such as Envelope #9 or Envelope C6,
choose User Defined... (For more information on envelope sizes, see Paper size on page 97.)
f Send the print data to the printer.
g After the printed page comes out of the printer, put in the next sheet of paper or envelope as shown in
Step d. Repeat for each page that you want to print.
Note
• The Error LED on the control panel will flash to indicate No paper in the manual feed slot until you put a
sheet of paper or envelope in the manual feed slot.
• Remove each sheet or envelope as soon as it has been printed. Stacking sheets or envelopes may cause
the paper to jam or curl.
