Driver and Software

You can change the following printer settings when you print from your computer.

 Paper Size

 Multiple Page

 Orientation

 Copies

 Media Type

 Paper Source

 Resolution

 Toner Save Mode

 Print Setting

 Manual Duplex printing

 Watermark

 Scaling

 Job Spooling

 Quick Print Setup

 Sleep Time

 Macro

 Header-Footer Print

 Density adjustment

 Error Message Printout

 Improve Print Output
