Control Panel

Drum error

The corona wire needs to be cleaned. See Cleaning the corona wire on page 69.

If your LED's still shows the same error indication after you have cleaned the corona

wire, replace the drum unit with a new one. See Replacing the drum unit on page 61.

LED Printer status
