Routine Maintenance
57
5
CAUTION
Wait to unpack the toner cartridge until immediately before you put it in the printer. If toner cartridges are
left unpacked for a long time the toner life will be shortened.
If an unpacked drum unit is put in direct sunlight or room light, the unit may be damaged.
Put the toner cartridge in the drum unit immediately after you have removed the protective cover. To prevent
any degradation to the print quality, DO NOT touch the shaded parts shown in the illustrations.
CAUTION
For USA and Canada
Ricoh strongly recommends that you do not refill the toner cartridge provided with your printer. We also
strongly recommend that you continue to use only genuine Ricoh brand replacement toner cartridges. Use
or attempted use of potentially incompatible toner and/or cartridges in the Ricoh machine may cause
damage to the machine and/or may result in unsatisfactory print quality. Our warranty coverage does not
apply to any problem that is caused by the use of unauthorized third party toner and/or cartridges. To protect
your investment and obtain premium performance from the Ricoh machine, we strongly recommend the use
of genuine Ricoh supplies.
