Routine Maintenance

c Wipe the outside of the printer with a dry, lint-free cloth to remove dust.

d Remove anything that is stuck inside the paper tray.

e Wipe the inside of the paper tray with a dry, lint-free cloth to remove dust.

f Put the paper tray back in the printer.

g Plug the printer back in, and then turn on the power switch.

Cleaning the inside of the printer 5

a Turn off the printer power switch and then unplug the printer.

b Open the front cover.
