7
GB
Option Effect Comments
Enabled with
programmes:
Delay Timer
Delays the start
of the wash by
up to 24 hours.
Press (SELECT button) repeatedly until the desired delay is
displayed. OFF indicates no delay has been set.
All
Bleaching
Bleaching cycle
designed to
remove the
toughest stains.
Please remember to pour the bleach into extra compartment 4
(se
e page 8)
. This option is incompatible with the EASY IRON
option.
2, 3, 4, 5,
6, 7, 8, 10,
Rinse cycles.
Easy iron
This option
reduces the
amount of
creasing on
fabrics, making
them easier to
iron.
If you set this option, programmes 6, 7, 8, 11 and Delicate Rinse
will be suspended, leaving the laundry to soak (Anti-crease) and
icon will flash:
- to conclude the cycle, press the START/RESET button;
- to run the draining cycle alone, set the knob to the relative
symbol and press the START/RESET button. This option is
incompatible with the BLEACHING option.
All
programmes
except for
1, 2, 9, 10
and Draining.
Super
Wash
Allows for an
impeccable wash,
visibly whiter than
a standard
Class
A
wash.
This option is incompatible with the RAPID option.
1, 2, 3, 4,
5, 6, 7, 8
Rapid
Cuts the duration
of the wash cycle
by 30%.
This option is incompatible with the SUPER WASH option.
1, 2, 3, 4,
5, 6, 7, 8
Extra Rinse
Increases the
efficiency of the
rinse.
Recommended when the appliance has a full load or with large
quantities of detergent.
1, 2, 3, 4, 5,
6, 7, 8, and
Rinse cycles.
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Personalisations
1. Press the MODE button to scroll through the various options available; the enabled symbol will flash.
2. To select it, press the SELECT button, until the word ON is displayed (for the Delay Timer, the time will be
displayed: see table below).
3. Confirm your setting by pressing the MODE button again: the symbol for the option will stop flashing on the
display.
The selected options can be seen on the display, as they are bordered by a frame.
Setting the temperature
Press button and the maximum temperature allowed for
the programme set will be displayed. Press the same button
to lower this temperature. OFF indicates a cold wash.
The temperature adjustment is enabled with all wash
programmes.
Setting the spin cycle
Press button and the maximum spin speed allowed for
the programme set will be displayed. Press the same
button to lower the value down to OFF, which indicates
that the spin cycle has been excluded altogether (press it
again to go back to the maximum value).
The spin cycle exclusion is indicated by symbol
.
The spin cycle setting is enabled with all the programmes
except for 11 and the Draining cycle.
Options
The various wash options available with this washing
machine will make for the desired results, every time.
To select the various options, the following procedure
should be followed at all times:
