Special Control Si39-501
92 Function
3.5.3 Stopping Operation of Slave Units During Master Unit is in Operation
With Multi-Outdoor-Unit System
While the master unit is in operation, this mode is used to set the refrigerant flow rate to a required level using a slave
unit in the stopped mode.
In cooling operation: The system operates in Mode A or Mode B listed in the table below.
The changeover operation for mode A and B is performed for the reason that the required refrigerant amount varies
depending on the indoor unit operation capacity.
Actuator Mode-A operation Mode-B operation
Compressor OFF OFF
Outdoor unit fan STEP4 OFF
Main motorized valve (EV1) 150 pls to 300 pls 0 pls
Subcooling motorized valve (EV2) 0 pls 0 pls
Hot gas bypass valve (SVP) ON ON
Receiver gas discharging valve
(SVG)
OFF OFF
Non-operating unit liquid pipe stop
valve (SVSL)
OFF ON
Mode transition conditions To Mode B when Tc
-
Tl >0.27×(Tc
-
Ta) +6
To Mode A when gas shortage signal
is sent from indoor unit
Ending conditions Slave units are required to operate.
Mode A : Operating unit collects refrigerant.
Mode B : Stopping unit storage refrigerant.
Operating
unit
Stopping
unit
∗ Mode A or B operation
