Si39-501 Basic Control
Function 85
2.3 Electronic Expansion Valve PI Control
Subcooling Motorized Valve EV2 Control
Makes PI control of the motorized valve (Y2E) to keep the superheated degree of the outlet gas
pipe on the evaporator side for the full use of the subcooling heat exchanger.
2.4 Step Control of Outdoor Unit Fans
Used to control the revolutions of outdoor unit fans in the steps listed in table below, according to condition changes.
* Figures listed above are all those controlled while in standard mode, which vary when the system is set to high static
pressure or capacity precedence mode.
SH = Tsh -Te SH : Outlet superheated degree of evaporator (°C)
Tsh : Suction pipe temperature detected with the
thermistor R5T (°C)
Te : Low pressure equivalent saturation
temperature (°C)
STEP
No.
Fan revolutions (rpm)
RXQ5MA RXQ8MA RXQ10MA RXQ12MA RXQ14MA RXQ16MA
0000000
1 300 300 300 300 300 300
2 320 320 320 325 325 325
3 350 345 345 355 355 355
4 385 385 385 400 400 400
5 470 465 465 500 500 500
6 585 575 575 605 605 605
7 800 765 785 880 880 880
8 840 825 825 920 920 920
