Basic Control Si39-501
84 Function
RXQ46MA, 48MA
(To increase Step No.)
STEP
No.
Master
unit
INV
Slave
unit1
INV
Slave
unit2
INV
STD
1 52Hz OFF OFF OFF
2 57Hz OFF OFF OFF
3 62Hz OFF OFF OFF
4 68Hz OFF OFF OFF
5 74Hz OFF OFF OFF
6 81Hz OFF OFF OFF
7 88Hz OFF OFF OFF
8 96Hz OFF OFF OFF
9 104Hz OFF OFF OFF
10 110Hz OFF OFF OFF
11 116Hz OFF OFF OFF
12 124Hz OFF OFF OFF
13 133Hz OFF OFF OFF
14 143Hz OFF OFF OFF
15 74Hz 74Hz OFF OFF
16 81Hz 81Hz OFF OFF
17 88Hz 88Hz OFF OFF
18 92Hz 92Hz OFF OFF
19 96Hz 96Hz OFF OFF
20 104Hz 104Hz OFF OFF
21 110Hz 110Hz OFF OFF
22 116Hz 116Hz OFF OFF
23 81Hz 81Hz 81Hz OFF
24 88Hz 88Hz 88Hz OFF
25 96Hz 96Hz 96Hz OFF
26 104Hz 104Hz 104Hz OFF
27 110Hz 110Hz 110Hz OFF
28 116Hz 116Hz 116Hz OFF
29 124Hz 124Hz 124Hz OFF
30 81Hz 81Hz 81Hz ON1
31 88Hz 88Hz 88Hz ON1
32 96Hz 96Hz 96Hz ON1
33 104Hz 104Hz 104Hz ON1
34 116Hz 116Hz 116Hz ON1
35 124Hz 124Hz 124Hz ON1
36 133Hz 133Hz 133Hz ON1
37 88Hz 88Hz 88Hz ON2
38 96Hz 96Hz 96Hz ON2
39 110Hz 110Hz 110Hz ON2
40 124Hz 124Hz 124Hz ON2
41 143Hz 143Hz 143Hz ON2
42 92Hz 92Hz 92Hz ON3
43 104Hz 104Hz 104Hz ON3
44 116Hz 116Hz 116Hz ON3
45 124Hz 124Hz 124Hz ON3
46 143Hz 143Hz 143Hz ON3
47 96Hz 96Hz 96Hz ON4
48 104Hz 104Hz 104Hz ON4
49 116Hz 116Hz 116Hz ON4
50 124Hz 124Hz 124Hz ON4
51 143Hz 143Hz 143Hz ON4
52 96Hz 96Hz 96Hz ON5
53 104Hz 104Hz 104Hz ON5
54 116Hz 116Hz 116Hz ON5
55 124Hz 124Hz 124Hz ON5
56 143Hz 143Hz 143Hz ON5
57 96Hz 96Hz 96Hz ON6
58 104Hz 104Hz 104Hz ON6
59 116Hz 116Hz 116Hz ON6
60 124Hz 124Hz 124Hz ON6
61 143Hz 143Hz 143Hz ON6
62 158Hz 158Hz 158Hz ON6
63 165Hz 165Hz 165Hz ON6
64 177Hz 177Hz 177Hz ON6
65 189Hz 189Hz 189Hz ON6
(To decrease Step No.)
STEP
No.
Master
unit
INV
Slave
unit1
INV
Slave
unit2
INV
STD
1 52Hz OFF OFF OFF
2 57Hz OFF OFF OFF
3 62Hz OFF OFF OFF
4 68Hz OFF OFF OFF
5 74Hz OFF OFF OFF
6 81Hz OFF OFF OFF
7 88Hz OFF OFF OFF
8 96Hz OFF OFF OFF
9 104Hz OFF OFF OFF
10 52Hz 52Hz OFF OFF
11 57Hz 57Hz OFF OFF
12 62Hz 62Hz OFF OFF
13 68Hz 68Hz OFF OFF
14 71Hz 71Hz OFF OFF
15 74Hz 74Hz OFF OFF
16 52Hz 52Hz 52Hz OFF
17 57Hz 57Hz 57Hz OFF
18 62Hz 62Hz 62Hz OFF
19 65Hz 65Hz 65Hz OFF
20 68Hz 68Hz 68Hz OFF
21 71Hz 71Hz 71Hz OFF
22 74Hz 74Hz 74Hz OFF
23 81Hz 81Hz 81Hz OFF
24 88Hz 88Hz 88Hz OFF
25 96Hz 96Hz 96Hz OFF
26 52Hz 52Hz 52Hz ON1
27 62Hz 62Hz 62Hz ON1
28 68Hz 68Hz 68Hz ON1
29 74Hz 74Hz 74Hz ON1
30 81Hz 81Hz 81Hz ON1
31 88Hz 88Hz 88Hz ON1
32 96Hz 96Hz 96Hz ON1
33 104Hz 104Hz 104Hz ON1
34 52Hz 52Hz 52Hz ON2
35 62Hz 62Hz 62Hz ON2
36 74Hz 74Hz 74Hz ON2
37 88Hz 88Hz 88Hz ON2
38 96Hz 96Hz 96Hz ON2
39 52Hz 52Hz 52Hz ON3
40 62Hz 62Hz 62Hz ON3
41 74Hz 74Hz 74Hz ON3
42 92Hz 92Hz 92Hz ON3
43 104Hz 104Hz 104Hz ON3
44 52Hz 52Hz 52Hz ON4
45 62Hz 62Hz 62Hz ON4
46 74Hz 74Hz 74Hz ON4
47 96Hz 96Hz 96Hz ON4
48 104Hz 104Hz 104Hz ON4
49 52Hz 52Hz 52Hz ON5
50 68Hz 68Hz 68Hz ON5
51 81Hz 81Hz 81Hz ON5
52 96Hz 96Hz 96Hz ON5
53 104Hz 104Hz 104Hz ON5
54 52Hz 52Hz 52Hz ON6
55 68Hz 68Hz 68Hz ON6
56 81Hz 81Hz 81Hz ON6
57 96Hz 96Hz 96Hz ON6
58 104Hz 104Hz 104Hz ON6
59 116Hz 116Hz 116Hz ON6
60 124Hz 124Hz 124Hz ON6
61 143Hz 143Hz 143Hz ON6
62 158Hz 158Hz 158Hz ON6
63 165Hz 165Hz 165Hz ON6
64 177Hz 177Hz 177Hz ON6
65 189Hz 189Hz 189Hz ON6
Notes:
1. INV : Inverter compressor
STD : Standard compressor
Figures after ON represent the number of STD compressors in operation.
2. “Master unit”, and “slave unit” in this section are the names for control, and they will be transferred according to the
priority of rotation system.
3. Depending on the operating conditions of compressors, the compressors may run in patterns other than those
aforementioned.
