Specifications Si39-501
46 Specifications
BEV Units
Connection Unit Series
Model BEVQ50MVE
Power Supply 1 Phase 50Hz 220~240V
Casing Galvanized Steel Plate
Dimensions: (H×W×D) mm 100×350×225
Sound Absorbing Thermal Insulation Material Flame and Heat Resistant Foamed Polyethylene
Piping
Connection
Indoor
Unit
Liquid Pipes 6.4mm (Flare Connection)
Gas Pipes 12.7mm (Flare Connection)
Outdoor
Unit
Liquid Pipes
6.4mm (Flare Connection)
Suction Gas Pipes
12.7mm (Flare Connection)
Machine Weight kg 3.0
Standard Accessories Installation manual, Gas piping connections, Insulation for fitting, Sealing material, Clamps
Drawing No. 4D046708
FXAQ20MH
FXAQ25MH
FXAQ32MH +
FXAQ40MH
FXAQ50MH
FXLQ20MH
FXLQ25MH
FXLQ32MH +
FXLQ40MH
FXLQ50MH
BEVQ50M
BEVQ50M
