Si39-501 Outline of Control (Indoor Unit)
Function 111
(2) Thermostat OFF by discharge air temperature
<Cooling>
6.7.3 Low Outdoor Air Temperature Protection Control
Objective In cooling (or fan operation) or heating, if outdoor air is low in temperature, stop the fan forcibly.
Details [Cooling and fan operation]
Turn OFF the fan for a period of 60 minutes at a suction temperature of 5
°
C or lower.
In order to monitor the outdoor air temperature, however, turn ON the fan for a period of one
minute and turn OFF the fan again at a temperature of 5
°
C or lower after the said timer
completes the operative period.
Reset the 60-minute timer when the fan stops running.
6.8 List of Swing Flap Operations
Swing flaps operate as shown in table below.
*1. L or LL only on FXFQ models
Target discharge air temp. Ts – Discharge air temp. T4
>5 degree continue for 5 minutes.
→
Thermostat stops for 1 minute.
→
Thermostat ON
Fan
Flap
FXFQ
FXCQ
FXHQ
FXKQ
FXAQ
Cooling
Thermostat ON in dry
operation using micro
computer
Swing L*
1
Swing Swing Swing
Wind direction set L*
1
Set Set Set
Thermostat OFF in dry
operation using micro
computer
Swing
OFF or L
Swing Swing Swing
Wind direction set Set Set Set
Thermostat OFF in
cooling
Swing Set Swing Swing Swing
Wind direction set Set Set Set Set
Stop
Swing OFF Horizontal Horizontal Totally closed
Wind direction set OFF Set Horizontal Totally closed
Micro computer control
(including cooling
operation)
Swing L Swing Swing Swing
Wind direction set L Set Set Set
