Specifications Si39-501
14 Specifications
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RXQ22MAY1 RXQ24MAY1
Model Name (Independent Unit) RXQ10MAY1+RXQ12MAY1 RXQ12MAY1+RXQ12MAY1
1 Cooling Capacity (19.5°CWB)
kcal / h 53,200 58,800
Btu / h 211,000 233,000
kW 61.9 68.4
2 Cooling Capacity (19.0°CWB) kW 61.5 67.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×930×765) (1600×930×765)+(1600×930×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53)×2 (13.72+10.53)×2
Number of Revolutions r.p.m (6480, 2900)×2 (6480, 2900)×2
Motor Output×Number
of Units
kW (1.6+4.5)+(2.8+4.5) (2.8+4.5)×2
Starting Method Direct on line (Inverter Drive) Direct on line (Inverter Drive)
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×2 0.75×2
Air Flow Rate m³/min 180+180 180+180
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
15.9 (Brazing Connection)
φ
15.9 (Brazing Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
φ
28.6 (Brazing Connection)
Product Mass (Machine Weight) kg 230+230 230+230
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Capacity Control % 7~100 6~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 8.6+9.0 9.0+9.0
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D039340, 4D039341 C: 4D049341
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
