Model Names of Indoor/Outdoor Units Si39-501
2 General Information
1. Model Names of Indoor/Outdoor Units
*Indoor Units
Note:FXDQ has following 2 Series, as show below. General, Asia (except for EU, China and Australia)
FXDQ-NVET: without Drain Pump
FXDQ-NVE: with Drain Pump
*Indoor Units (Connection Unit Series)
Note:BEV unit is required for each indoor unit.
Outdoor Units
*Note: Refer to the Engineering Data of ED39-428B concerning about the informations of Indoor Units.
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — —
VE
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Cassette Corner
Type
FXKQ — 25M 32M 40M — 63M — — — — —
Slim Ceiling Mounted
Duct Type
FXDQ 20N 25N 32N 40N 50N 63N — — — — —
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Duct Type
FXMQ — — — 40M 50M 63M 80M 100M 125M 200M 250M
Ceiling Suspended
Type
FXHQ — — 32M — — 63M — 100M — — —
Wall Mounted Type
FXAQ 20M 25M 32M 40M 50M 63M — — — — —
Floor Standing Type
FXLQ 20M 25M 32M 40M 50M 63M — — — — —
Concealed Floor
Standing Type
FXNQ 20M 25M 32M 40M 50M 63M — — — — —
Type Model Name Power Supply
Ceiling Suspended
Cassette Type
FXUQ ——————71M100M 125M — —
V1
Wall Mounted
Type
FXAQ
20MH 25MH 32MH 40MH 50MH
——————
Floor Standing
Type
FXLQ
20MH 25MH 32MH 40MH 50MH
——————
Connection Unit BEVQ-M 50M 50M 50M 50M 50M — 71M 100M 125M — — VE
Series Model Name Power Supply
Cooling Only RXQ 5MA 8MA 10MA 12MA 14MA 16MA 18MA 20MA 22MA 24MA 26MA Y1
Series Model Name Power Supply
Cooling Only RXQ 28MA 30MA 32MA 34MA 36MA 38MA 40MA 42MA 44MA 46MA 48MA Y1
VE: 1
φ
, 220~240V, 50Hz, 1
φ,
220V, 60Hz
V1: 1
φ
, 220~240V, 50Hz
Y1: 3
φ
, 380~415V, 50Hz
