![Daikin RXQ26MAY1 [17/344] Model selection](/views2/1707036/page17/bg11.png)
Model Selection Si39-501
6 General Information
4. Model Selection
VRV II Cooling Only Series
Connectable indoor units number and capacity
HP 5HP 8HP 10HP 12HP 14HP 16HP
System name RXQ5MA RXQ8MA RXQ10MA RXQ12MA RXQ14MA RXQ16MA
Outdoor unit 1 RXQ5MA RXQ8MA RXQ10MA RXQ12MA RXQ14MA RXQ16MA
Outdoor unit 2 ––––––
Outdoor unit 3 ––––––
Total number of connectable indoor units 8 13 16 20 20 20
Total capacity of connectable indoor units (kW)
7.0~18.2 11.2~29.1 14.0~36.4 16.8~43.6 20.0~52.0 22.5~58.5
HP 18HP 20HP 22HP 24HP 26HP 28HP
System name RXQ18MA RXQ20MA RXQ22MA RXQ24MA RXQ26MA RXQ28MA
Outdoor unit 1 RXQ8MA RXQ10MA RXQ10MA RXQ12MA RXQ10MA RXQ12MA
Outdoor unit 2 RXQ10MA RXQ10MA RXQ12MA RXQ12MA RXQ16MA RXQ16MA
Outdoor unit 3 ––––––
Total number of connectable indoor units 20 20 22 32 32 32
Total capacity of connectable indoor units (kW)
25.2~65.5 28.0~72.8 30.8~80.0 34.0~88.4 36.5~94.9 39.3~102.1
HP 30HP 32HP 34HP 36HP 38HP 40HP
System name RXQ30MA RXQ32MA RXQ34MA RXQ36MA RXQ38MA RXQ40MA
Outdoor unit 1 RXQ14MA RXQ16MA RXQ10MA RXQ12MA RXQ12MA RXQ12MA
Outdoor unit 2 RXQ16MA RXQ16MA RXQ12MA RXQ12MA RXQ12MA RXQ12MA
Outdoor unit 3 – – RXQ12MA RXQ12MA RXQ14MA RXQ16MA
Total number of connectable indoor units 32 32 34 36 38 40
Total capacity of connectable indoor units (kW)
42.5~110.5 45.0~117.0 48.0~124.8 50.5~131.3 53.3~138.5 56.5~146.9
HP 42HP 44HP 46HP 48HP
System name RXQ42MA RXQ44MA RXQ46MA RXQ48MA
Outdoor unit 1 RXQ10MA RXQ12MA RXQ14MA RXQ16MA
Outdoor unit 2 RXQ16MA RXQ16MA RXQ16MA RXQ16MA
Outdoor unit 3 RXQ16MA RXQ16MA RXQ16MA RXQ16MA
Total number of connectable indoor units 40 40 40 40
Total capacity of connectable indoor units (kW)
59.0~153.4 61.8~160.6 65.0~169.0 67.5~175.5
