Other Control Si39-501
102 Function
• In order to set the slave unit 1 to operation
prohibition mode, set No. 39 of Setting mode 2 to
"SLAVE 1 OPERATION PROHIBITION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 39 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• In order to set the slave unit 2 to operation
prohibition mode, set No. 40 of Setting mode 2 to
"SLAVE 2 OPERATION PROHIBITION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 40 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
∗
• In the case of multi-outdoor-unit system, “Inhibition of operation” is not set with each
compressor individually.
• In the case of multi-outdoor-unit system, when the above “Inhibition of operation” is set,
outdoor unit rotation is not functional.
5.3 Demand Operation
In order to save the power consumption, the capacity of outdoor unit is saved with control
forcibly by using “Demand 1 Setting” or “Demand 2 Setting”.
To operate the unit with this mode, additional setting of “Continuous Demand Setting” or
external input by external control adapter is required.
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
77
77
77777
7
77777
9
7
7777
9
7
7
777777
77
777
7777
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
77
7
77
777
7
77777
9
7
7777
9
7
7
777777
77
777
7777
Note : Reset the power supply during the outdoor unit is stopping to cancel the
automatic backup operation forcibly.
Set item Condition Content
Demand 1 Mode 1 The compressor operates at approx. 60% or less of rating.
Mode 2 The compressor operates at approx. 70% or less of rating.
Mode 3 The compressor operates at approx. 80% or less of rating.
Demand 2 The compressor operates at approx. 40% or less of rating.
