Si39-501 Selection of Pipe Size, Joints and Header
Appendix 311
6.2.6 Outdoor Unit Multi Connection Piping Kit
Select the piping kit according to the No. of outdoor units
6.2.7 Piping between REFNET Joint and Indoor Unit
Pipe size for direct connection to indoor unit must be the same as the connection size of indoor
unit.
6.2.8 Piping between outdoor Unit and Multi Connection Piping Kit
Pipe size for direct connection to outdoor unit must be the same as the connection size of
outdoor unit.
No. of outdoor units Multi Connection Piping Kit
2 units BHFP22MA90
3 units BHFP22MA135
Connection pipe size of indoor unit.
Indoor Units Gas Liquid
20 · 25 · 32 · 40 · 50 Type
φ
12.7
φ
6.4
63 · 80 · 100 · 125 Type φ15.9 φ9.5
200 Type φ19.1
250 Type φ22.2
Outdoor Units Gas Liquid Oil
RXQ8MAY1 φ19.1 φ9.5 φ6.4
RXQ10MAY1, 12MAY1 φ22.2
RXQ14MAY1, 16MAY1 φ28.6 φ12.7
