Daikin RXQ34MAY1 [92/344] Notes 1 inv inverter compressor std standard compressor figures after on represent the number of std compressors in operation 2 master unit and slave unit in this section are the names for control and they will be transferred according to the priority of rotation system 3 depending on the operating conditions of compressors the compressors may run in patterns other than those aforementioned
![Daikin RXQ36MAY1 [92/344] Notes 1 inv inverter compressor std standard compressor figures after on represent the number of std compressors in operation 2 master unit and slave unit in this section are the names for control and they will be transferred according to the priority of rotation system 3 depending on the operating conditions of compressors the compressors may run in patterns other than those aforementioned](/views2/1707036/page92/bg5c.png)
Si39-501 Basic Control
Function 81
(To increase Step No.)
STEP
No.
Master
unit
INV
Slave
unit
INV
STD
1 52Hz OFF OFF
2 57Hz OFF OFF
3 62Hz OFF OFF
4 68Hz OFF OFF
5 74Hz OFF OFF
6 81Hz OFF OFF
7 88Hz OFF OFF
8 96Hz OFF OFF
9 104Hz OFF OFF
10 110Hz OFF OFF
11 116Hz OFF OFF
12 124Hz OFF OFF
13 133Hz OFF OFF
14 143Hz OFF OFF
15 74Hz 74Hz OFF
16 81Hz 81Hz OFF
17 88Hz 88Hz OFF
18 92Hz 92Hz OFF
19 96Hz 96Hz OFF
20 104Hz 104Hz OFF
21 110Hz 110Hz OFF
22 116Hz 116Hz OFF
23 124Hz 124Hz OFF
24 133Hz 133Hz OFF
25 143Hz 143Hz OFF
26 158Hz 158Hz OFF
27 165Hz 165Hz OFF
28 177Hz 177Hz OFF
29 81Hz 81Hz ON1
30 88Hz 88Hz ON1
31 96Hz 96Hz ON1
32 104Hz 104Hz ON1
33 116Hz 116Hz ON1
34 124Hz 124Hz ON1
35 133Hz 133Hz ON1
36 88Hz 88Hz ON2
37 96Hz 96Hz ON2
38 110Hz 110Hz ON2
39 124Hz 124Hz ON2
40 143Hz 143Hz ON2
41 158Hz 158Hz ON2
42 165Hz 165Hz ON2
43 177Hz 177Hz ON2
44 189Hz 189Hz ON2
45 202Hz 202Hz ON2
46 210Hz 210Hz ON2
Notes:
1. INV : Inverter compressor
STD : Standard compressor
Figures after ON represent the number of STD compressors in operation.
2. “Master unit”, and “slave unit” in this section are the names for control, and they will be transferred according to the
priority of rotation system.
3. Depending on the operating conditions of compressors, the compressors may run in patterns other than those
aforementioned.
(To decrease Step No.)
STEP
No.
Master
unit
INV
Slave
unit
INV
STD
1 52Hz OFF OFF
2 57Hz OFF OFF
3 62Hz OFF OFF
4 68Hz OFF OFF
5 74Hz OFF OFF
6 81Hz OFF OFF
7 88Hz OFF OFF
8 96Hz OFF OFF
9 104Hz OFF OFF
10 52Hz 52Hz OFF
11 57Hz 57Hz OFF
12 62Hz 62Hz OFF
13 68Hz 68Hz OFF
14 71Hz 71Hz OFF
15 74Hz 74Hz OFF
16 81Hz 81Hz OFF
17 88Hz 88Hz OFF
18 92Hz 92Hz OFF
19 96Hz 96Hz OFF
20 104Hz 104Hz OFF
21 110Hz 110Hz OFF
22 116Hz 116Hz OFF
23 124Hz 124Hz OFF
24 133Hz 133Hz OFF
25 52Hz 52Hz ON1
26 62Hz 62Hz ON1
27 68Hz 68Hz ON1
28 74Hz 74Hz ON1
29 81Hz 81Hz ON1
30 88Hz 88Hz ON1
31 96Hz 96Hz ON1
32 104Hz 104Hz ON1
33 52Hz 52Hz ON2
34 62Hz 62Hz ON2
35 74Hz 74Hz ON2
36 88Hz 88Hz ON2
37 96Hz 96Hz ON2
38 110Hz 110Hz ON2
39 124Hz 124Hz ON2
40 143Hz 143Hz ON2
41 158Hz 158Hz ON2
42 165Hz 165Hz ON2
43 177Hz 177Hz ON2
44 189Hz 189Hz ON2
45 202Hz 202Hz ON2
46 210Hz 210Hz ON2
