Refrigerant Circuit Si39-501
54 Refirgerant Circuit
1.2 RXQ8MA, 10MA
No. in
refrigerant
system
diagram
Symbol Name Major Function
A M1C Inverter compressor (INV) Inverter compressor is operated on frequencies between 52 Hz and 210 Hz by using
the inverter, while Standard compressor is operated with commercial power supply
only. The number of operating steps is as follows when Inverter compressor is
operated in combination with Standard compressor.
RXQ8, 10MA: 37 steps
BM2C
Standard compressor 1
(STD1)
D M1F Inverter fan
Since the system is of air heat exchanging type, the fan is operated at 9-step rotation
speed by using the inverter.
EY1E
Electronic expansion valve
(Main: EV1)
Fully open during cooling operation.
FY2E
Electronic expansion valve
(Subcool: EV2)
PI control is applied to keep the outlet superheated degree of subcooling heat
exchanger constant.
G Y1S Solenoid valve (Hot gas: SVP) Used to prevent the low pressure from transient falling.
JY2S
Solenoid valve (Receiver gas
discharging: SVG)
Used to collect refrigerant to receiver.
LY3S
Solenoid valve (Non-operating
unit liquid pipe closing: SVSL)
Used to prevent the accumulation of refrigerant in non-operating outdoor units in the
case of multi-outdoor unit system.
N S1NPH High pressure sensor Used to detect high pressure.
O S1NPL Low pressure sensor Used to detect low pressure.
PS1PH
HP pressure switch (For INV
compressor)
In order to prevent the increase of high pressure when a malfunction occurs, this
switch is activated at high pressure of 4.0 MPa or more to stop the compressor
operation.
QS2PH
HP pressure switch (For STD
compressor 1)
S — Fusible plug
In order to prevent the increase of pressure when abnormal heating is caused by fire
or others, the fusible part of the plug is molten at a temperature of 70 to 75°C to
release the pressure into the atmosphere.
U —
Pressure regulating valve 2
(Liquid pipe to receiver)
This valve opens at a pressure of 2 to 2.7 MPa for prevention of pressure increase,
thus resulting in no damage of functional parts due to the increase of pressure in
transportation or storage.
V — Piping heat exchanger Used to heat the gas refrigerant from the liquid receiver.
W — Capillary tube
Used to return the refrigerating oil separated through the oil separator to the INV
compressor.
X — Capillary tube
Used to return the refrigerating oil separated through the oil separator to the STD1
compressor.
1 R1T Thermistor (Outdoor air: Ta) Used to detect outdoor temperature, correct discharge pipe temperature, and others.
2 R1T Thermistor (Fin)
Used to detect fin temperature of inverter PC board, make the temperature protection
of inverter PC board.
3 R2T Thermistor (Suction pipe: Ts) Used to detect suction pipe temperature.
4 R31T
Thermistor (INV discharge
pipe: Tdi)
Used to detect discharge pipe temperature, make the temperature protection control of
compressor, and others.
5 R32T
Thermistor (STD1 discharge
pipe: Tds1)
6R4T
Thermistor (Heat exchanger
outlet: Tb)
Used to detect liquid pipe temperature of air heat exchanger.
7R5T
Thermistor (Subcooling heat
exchanger gas pipe: Tsh)
Used to detect gas pipe temperature on the evaporation side of subcooling heat
exchanger, keep the superheated degree at the outlet of subcooling heat exchanger
constant, and others.
8R6T
Thermistor (Receiver outlet
liquid pipe: Tl)
Used to detect receiver outlet liquid pipe temperature.
