Refrigerant Circuit Si39-501
52 Refirgerant Circuit
1. Refrigerant Circuit
1.1 RXQ5MA
No. in
refrigerant
system
diagram
Symbol Name Major Function
A M1C Inverter compressor (INV)
Inverter compressor is operated on frequencies between 52 Hz and 210 Hz by using
the inverter. The number of operating steps is as follows when Inverter compressor is
operated.
RXQ5MA : 20 steps
D M1F Inverter fan
Since the system is of air heat exchanging type, the fan is operated at 9-step rotation
speed by using the inverter.
EY1E
Electronic expansion valve
(Main: EV1)
Fully open during cooling operation.
G Y1S Solenoid valve (Hot gas: SVP) Used to prevent the low pressure from transient falling.
JY2S
Solenoid valve (Receiver gas
discharging: SVG)
Used to collect refrigerant to receiver.
K Y4S Solenoid valve (Injection)
Used to cool the compressor by injecting refrigerant when the compressor discharge
temperature is high.
N S1NPH High pressure sensor Used to detect high pressure.
O S1NPL Low pressure sensor Used to detect low pressure.
PS1PH
HP pressure switch (For INV
compressor)
In order to prevent the increase of high pressure when a malfunction occurs, this
switch is activated at high pressure of 4.0 MPA or more to stop the compressor
operation.
S — Fusible plug
In order to prevent the increase of pressure when abnormal heating is caused by fire
or others, the fusible part of the plug is molten at a temperature of 70 to 75°C to
release the pressure into the atmosphere.
T—
Pressure regulating valve 1
(Receiver to discharge pipe)
This valve opens at a pressure of 2 to 2.7 MPa for prevention of pressure increase,
thus resulting in no damage of functional parts due to the increase of pressure in
transportation or storage.
V — Piping heat exchanger Used to heat the gas refrigerant from the liquid receiver.
W — Capillary tube
Used to return the refrigerating oil separated through the oil separator to the
compressor.
1 R1T Thermistor (Outdoor air: Ta) Used to detect outdoor temperature, correct discharge pipe temperature, and others.
2 R1T Thermistor (Fin)
Used to detect fin temperature of inverter PC board, make the temperature protection
of inverter PC board.
3 R2T Thermistor (Suction pipe: Ts) Used to detect suction pipe temperature.
4R3T
Thermistor (INV discharge
pipe: Tdi)
Used to detect discharge pipe temperature, make the temperature protection control of
compressor, and others.
5R4T
Thermistor (Heat exchanger
outlet: Tb)
Used to detect liquid pipe temperature of air heat exchanger.
6R5T
Thermistor (Sub-cooling heat-
exchanger gas pipe)
Used to judge the refrigerant overcharge at the check operation.
