Si39-501 Selection of Pipe Size, Joints and Header
Appendix 309
6.2 RXQ18MAY1, RXQ20MAY1, RXQ22MAY1,
RXQ24MAY1, RXQ26MAY1, RXQ28MAY1,
RXQ30MAY1, RXQ32MAY1, RXQ34MAY1,
RXQ36MAY1, RXQ38MAY1, RXQ40MAY1,
RXQ42MAY1, RXQ44MAY1, RXQ46MAY1,
RXQ48MAY1
6.2.1 How to select the REFNET Joint
How to select the REFNET Joint
Select the REFNET Joint from the following table.When using REFNET Joints at the first branch
counted from the outdoor unit side.
For REFNET Joints other than the first branch, select the proper ones based on the total
capacity index of the indoor units installed after the first branch using the following table :
6.2.2 How to select pipe size
Main Piping (Between Multi connection piping kit and REFNET Joint)
Select the proper ones based on the following table :
Piping Material
Select the piping material to be used from the next table according to piping size.
(Ex. : REFNET Joint A)
Outdoor Unit REFNET Joint (Kit Name)
RXQ18MAY1-24MAY1 KHRP26M72T
RXQ26MAY1-48MAY1 KHRP26M73T+KHRP26M73TP
Total capacity index of indoor units REFNET Joints (Kit Name)
<200 KHRP26M22T
200≤X<290 KHRP26M33T
290≤X<640 KHRP26M72T
640≤ KHRP26M73T+KHRP26M73TP
Outdoor Unit Gas Liquid
RXQ18MAY1
φ
28.6
φ
12.7
RXQ20MAY1
φ
15.9
RXQ22MAY1
RXQ24MAY1
RXQ26MAY1
φ
34.9
φ
19.1
RXQ28MAY1
RXQ30MAY1
RXQ32MAY1
RXQ34MAY1
RXQ36MAY1
RXQ38MAY1 φ41.3
RXQ40MAY1
RXQ42MAY1
RXQ44MAY1
RXQ46MAY1
RXQ48MAY1
Piping Size (O / D) Temper grade of Material
φ15.9 or less O * O: Soft (Annealed)
φ19.1 or more 1 / 2H or H * H: Hard (Drawn)
