Si39-501 Troubleshooting by Remote Controller
Troubleshooting 169
Outdoor
Unit
LA 999Malfunction of power unit —
LC 999Malfunction of transmission between inverter and
control PC board
212
P1 999Inverter over-ripple protection 214
P4 999Malfunction of inverter radiating fin temperature rise
sensor
215
System
U0 879Low pressure drop due to refrigerant shortage or
electronic expansion valve failure
216
U1 999Reverse phase / open phase 217
U2 999Power supply insufficient or instantaneous failure 218
U3 999Check operation is not conducted. 220
U4 999Malfunction of transmission between indoor and
outdoor units
221
U5 999Malfunction of transmission between remote
controller and indoor unit
223
U5 787Failure of remote controller PC board or setting
during control by remote controller
223
U7 999Malfunction of transmission between outdoor units 224
U8 997Malfunction of transmission between main and sub
remote controllers (malfunction of sub remote controller)
226
U9 999Malfunction of transmission between indoor unit and
outdoor unit in the same system
227
UA 999Improper combination of indoor and outdoor units,
indoor units and remote controller
229
UC 888Address duplication of central remote controller 230
UE 999Malfunction of transmission between central remote
controller and indoor unit
231
241
UF 999Refrigerant system not set, incompatible wiring /
piping
233
UH 999Malfunction of system, refrigerant system address
undefined
234
Central
Remote
Controller
and
Schedule
Timer
M1 8 or 79 9Central remote controller PC board defect
Schedule timer PC board defect
235
243
M8 8 or 79 9Malfunction of transmission between optional
controllers for centralized control
236
244
MA 8 or 79 9Improper combination of optional controllers for
centralized control
238
245
MC 8 or 79 9Address duplication, improper setting 240
247
Heat
Reclaim
Ventilation
64 879Indoor unit’s air thermistor error —
65 879Outside air thermistor error —
68 879 —
6A 879Damper system alarm —
6A 999Damper system + thermistor error —
6F 879Malfunction of simple remote controller —
6H 879Malfunction of door switch or connector —
94 999Internal transmission error —
8: ON 7: OFF 9: Blink
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
The system operates for malfunction codes indicated in black squares, however, be sure to check and repair.
