Daikin RXQ34MAY1 [76/344] Cooling oil return operation
![Daikin RXQ10MAY1 [76/344] Cooling oil return operation](/views2/1707036/page76/bg4c.png)
Si39-501 Refrigerant Flow for Each Operation Mode
Refirgerant Circuit 65
Cooling Oil Return Operation
Thermostat "OFF"
" OFF " " ON "
" ON "
FanFan
Indoor unit operation
Fan OFF
Indoor unit
Electronic expansion valve
EV:200pls
FilterFilter
Heat exchanger
Fan OFF
Indoor unit
Electronic expansion valve
EV:200pls
FilterFilter
Heat exchanger
Fan ON
Thermostat "ON"
Indoor unit
"High temperature, high pressure gas"
"High temperature, high pressure liquid"
"Low temperature, low pressure"
Heat exchanger
Electronic expansion valve
EV:Nomal
control
FilterFilter
Fan
