Basic Control Si39-501
80 Function
Compressor Step Control
Compressor operations vary with the following steps according to information in "2.2 Compressor PI Control".
Furthermore, the operating priority of compressors is subject to information in "
Operating Priority and Rotation of
Compressors".
RXQ5MA
STEP
No.
INV
1 52Hz
2 57Hz
3 62Hz
4 68Hz
5 74Hz
6 81Hz
7 88Hz
8 96Hz
9 104Hz
10 110Hz
11 116Hz
12 124Hz
13 133Hz
14 143Hz
15 158Hz
16 165Hz
17 177Hz
18 189Hz
19 202Hz
20 210Hz
RXQ8MA,10MA,12MA
STEP
No.
INV STD1
1 52Hz OFF
2 57Hz OFF
3 62Hz OFF
4 68Hz OFF
5 74Hz OFF
6 81Hz OFF
7 88Hz OFF
8 96Hz OFF
9 104Hz OFF
10 110Hz OFF
11 116Hz OFF
12 124Hz OFF
13 133Hz OFF
14 143Hz OFF
15 158Hz OFF
16 165Hz OFF
17 177Hz OFF
18 189Hz OFF
19 202Hz OFF
20 210Hz OFF
21 52Hz ON
22 62Hz ON
23 68Hz ON
24 74Hz ON
25 81Hz ON
26 88Hz ON
27 96Hz ON
28 104Hz ON
29 116Hz ON
30 124Hz ON
31 133Hz ON
32 143Hz ON
33 158Hz ON
34 177Hz ON
35 189Hz ON
36 202Hz ON
37 210Hz ON
RXQ14MA,16MA
STEP
No.
INV STD1 STD2
1 52Hz OFF OFF
2 57Hz OFF OFF
3 62Hz OFF OFF
4 68Hz OFF OFF
5 74Hz OFF OFF
6 81Hz OFF OFF
7 88Hz OFF OFF
8 96Hz OFF OFF
9 104Hz OFF OFF
10 110Hz OFF OFF
11 116Hz OFF OFF
12 124Hz OFF OFF
13 133Hz OFF OFF
14 143Hz OFF OFF
15 158Hz OFF OFF
16 165Hz OFF OFF
17 177Hz OFF OFF
18 189Hz OFF OFF
19 202Hz OFF OFF
20 210Hz OFF OFF
21 52Hz ON OFF
22 62Hz ON OFF
23 68Hz ON OFF
24 74Hz ON OFF
25 81Hz ON OFF
26 88Hz ON OFF
27 96Hz ON OFF
28 104Hz ON OFF
29 116Hz ON OFF
30 124Hz ON OFF
31 133Hz ON OFF
32 143Hz ON OFF
33 158Hz ON OFF
34 177Hz ON OFF
35 189Hz ON OFF
36 202Hz ON OFF
37 210Hz ON OFF
38 52Hz ON ON
39 62Hz ON ON
40 74Hz ON ON
41 88Hz ON ON
42 96Hz ON ON
43 110Hz ON ON
44 124Hz ON ON
45 143Hz ON ON
46 158Hz ON ON
47 165Hz ON ON
48 177Hz ON ON
49 189Hz ON ON
Notes:
1. INV : Inverter compressor
STD1 : Standard compressor 1
STD2 : Standard compressor 2
2. Depending on the operating conditions of compressors, the compressors may run in patterns other than those
aforementioned.
