Si39-501 Selection of Pipe Size, Joints and Header
Appendix 307
6. Selection of Pipe Size, Joints and Header
6.1 RXQ5MAY1, RXQ8MAY1, RXQ10MAY1,
RXQ12MAY1, RXQ14MAY1,
RXQ16MAY1
6.1.1 How to select the REFNET Joint
How to select the REFNET Joint
Select the REFNET Joint from the following table when using REFNET Joints at the first branch
counted from the outdoor unit side.
(Ex. : REFNET Joint A)
For REFNET Joints other than the first branch, select the proper ones based on the total
capacity index of the indoor units installed after the first branch using the following table :
6.1.2 How to select pipe size
Between outdoor unit and uppermost stream REFNET Joint.
Piping Material
Select the piping material to be used from the next table according to piping size.
Wall thickness of refrigerant pipe
(Unit : mm)
∗The table shows the requirements of Japanese High Pressure Gas Control low. The thickness
and material shall be selected in accordance with local code. (As of Jan.2003)
Outdoor Unit REFNET Joints (Kit Name)
RXQ5MAY1 KHRP26M22T
RXQ8MAY1, 10MAY1, 12MAY1 KHRP26M33T
RXQ14MAY1, 16MAY1 KHRP26M72T
Total capacity index of indoor units REFNET Joints (Kit Name)
<200 KHRP26M22T
200≤X<290 KHRP26M33T
290≤X<640 KHRP26M72T
Pipe size connected to outdoor unit.
Outdoor Unit Gas Liquid
RXQ5MAY1
φ
15.9
φ
9.5
RXQ8MAY1 φ19.1
RXQ10MAY1, 12MAY1
φ
22.2
RXQ14MAY1, 16MAY1 φ28.6 φ12.7
Piping Size (O / D) Temper grade of Material
φ15.9 or less O * O: Soft (Annealed)
φ19.1 or more 1 / 2H or H * H: Hard (Drawn)
Temper grade O Type 1/2H Type
Copper tube O.D
φ6.4 φ9.5 φ12.7 φ15.9 φ19.1 φ22.2 φ25.4 φ28.6 φ31.8 φ34.9 φ38.1 φ41.3
Copper tube W.T
(Minimum
requirement)
0.80 0.80 0.80 0.99 0.80 0.80 0.88 0.99 1.10 1.21 1.32 1.43
