Specifications Si39-302
12 Specifications
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m,
level difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m,
level difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m,
level difference : 0m.
Model Name RXYQ14MY1B RXYQ16MY1B
★
1 Cooling Capacity (19.5°CWB)
kcal / h 35,500 40,000
Btu / h 141,000 157,000
kW 41.3 45.9
★
2 Cooling Capacity (19.0°CWB) kW 40.0 44.5
★
3 Heating Capacity
kcal / h 38,700 43,000
Btu / h 154,000 171,000
kW 45.0 50.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1600×1240×765 1600×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Displacement m³/h 13.72+10.47+10.47 13.72+10.47+10.47
Number of Revolutions r.p.m 6480, 2900×2 6480, 2900×2
Motor Output×Number
of Units
kW (2.0+4.5+4.5)×1 (3.0+4.5+4.5)×1
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.75×1
Air Flow Rate m³/min 210 210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
φ
28.6 (Brazing Connection)
Oil Equalizing Pipe mm — —
Machine Weight kg 323 325
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 10~100 10~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 12.9 14.4
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil Synthetic (ether) oil
Charge Volume L 1.9+1.6+1.6 1.9+1.6+1.6
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038968A 4D038969A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
